Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 07KR91 |
| Product Code | GJR5250000R0101 |
| Memory | 7K FLASH EPROM |
| Inputs | 20 × 24V DC Digital Inputs |
| Outputs | 12 × 2A Relay Outputs |
| Communication Ports | 1 × RS232, 1 × RS485 |
| Real-Time Clock | Integrated |
| High-Speed Counter | 10 kHz |
| Control Functions | Data handling, PID regulation |
| Programming Interface | RS232 9-pin D-sub connector (female) |
| Bus Type | CS31 Bus (RS485) — supports up to 31 remote units |
| Power Supply Options | 24 VDC (GJR5250000R0252), 120/230 VAC (GJR5250000R0202) |
| Mounting | DIN rail or screw (Ø 4 mm) |
| Degree of Protection | IP20 |
| Operating Temperature | 0 °C to +55 °C |
| Storage Temperature | -40 °C to +75 °C |
| Dimensions (W×H×D) | 240 × 140 × 85 mm |
| Weight | 1.6 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of memory does the 07KR91 CPU use?
A1: It uses 7K FLASH EPROM memory.
Q2: How many digital inputs and outputs are available on the 07KR91?
A2: It has 20 digital inputs and 12 relay outputs.
Q3: What communication interfaces are supported?
A3: It supports RS232 and RS485 interfaces.
Q4: Does the CPU support real-time functions?
A4: Yes, it has a built-in real-time clock and high-speed counter.
Q5: Can the unit be mounted on a DIN rail?
A5: Yes, it supports both DIN rail and screw mounting.
Q6: What is the maximum number of remote I/O units supported?
A6: The CS31 bus supports up to 31 remote slave units.
Q7: What are the environmental operating limits?
A7: The operating temperature is 0°C to 55°C, storage from -40°C to 75°C.
Q8: Is PID control functionality supported?
A8: Yes, PID control is included as part of the advanced functionality.
