Technical Specifications
| Item | Specification |
|---|---|
| Model | 07KT98 GJR5253100R4278 |
| Digital Inputs | 24 channels (3 groups of 8, optically isolated) |
| Digital Outputs | 16 channels (2 groups of 8, transistor type with short-circuit protection) |
| Digital I/O | 8 configurable channels (input/output or read-back output) |
| Analog Inputs | 8 configurable channels (voltage, current, Pt100, differential) |
| Analog Outputs | 4 channels (0…10V, 0…20mA, 4…20mA configurable) |
| High-Speed Counter | Integrated, max. 50 kHz, 7 operation modes |
| Serial Interfaces | 2 (COM1, COM2 – RS-232, Modbus supported) |
| System Bus Interface | CS31 system bus |
| Real-Time Clock | Integrated |
| Memory | 1MB user program, 1MB user data, 256KB RETAIN, 128KB Flash EPROM |
| Programming Software | 907 AC 1131 V4.1 or later |
| Power Supply Voltage | 24V DC |
| Max. Current Consumption | 0.55 A |
| Dimensions (W x H x D) | 240 x 140 x 85 mm |
| Weight | 1.6 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What communication protocols does the 07KT98 support?
A1: It supports Modbus, CS31, PROFIBUS-DP, ARCNET, CANopen, and Ethernet.
Q2: Does it support high-speed counting?
A2: Yes, it has a built-in high-speed counter supporting up to 50 kHz with 7 modes.
Q3: What signal types are supported by the analog inputs?
A3: Supports 0…10V, ±10V, 0…20mA, 4…20mA, and Pt100 (2-wire or 3-wire).
Q4: Are the digital outputs protected?
A4: Yes, digital outputs are protected against short-circuits and overloads.
Q5: Does the unit offer data retention after power loss?
A5: Yes, with integrated lithium battery (07 LE 90) and Flash EPROM.
Q6: Can analog inputs be configured as digital inputs?
A6: Yes, analog inputs can be used as digital inputs.
Q7: Can the controller be used as master or slave?
A7: Yes, it can function as a standalone unit, master, or slave in CS31.
Q8: What versions of programming software are supported?
A8: It supports 907 AC 1131 software version V4.1 or later, depending on the interface.
