Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | 81EA11D-E |
| Order Number | GJR2374800R0210 |
| Product Series | Procontrol P14 |
| Module Type | Analog Input Module |
| Resistor Design | 2.7 kΩ resistor |
| Power Capacity | 0.25 W |
| Operating Temp. | 0°C to +70°C |
| Storage Temp. | -40°C to +85°C |
| Dimensions | 100 x 120 x 75 mm |
| Weight | 0.25 kg |
| Mounting Method | Plug-in type (cabinet connector side) |
| Applicable Terminals | EXX1 and EXX2 |
| Compatible Sim. Mod. | 81ES01/R0300 (for unused channel wiring simulatio |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the 81EA11D-E module?
A1: It is an analog input module designed for ABB Procontrol P14 systems, used to acquire analog signal inputs.
Q2: Can the 81EA11D-E module operate independently?
A2: No, it operates as part of a system and must be connected to the controller and I/O bus.
Q3: How should unused input units be handled?
A3: For versions R0200/R0210, unused channels must be wired using the 81ES01/R0300 transmitter simulation module.
Q4: What is the operating temperature range for the module?
A4: The operating temperature range is from 0°C to 70°C.
Q5: What is the internal resistance value of the module?
A5: It uses a 2.7 kΩ resistor with a power capacity of 0.25 W.
Q6: How are unused input terminals connected?
A6: They are connected via EXX1 and EXX2 terminals using simulation modules or jumpers.
Q7: Does the module support plug-in installation?
A7: Yes, it features a plug-in design for easy installation and replacement.
Q8: What are the dimensions and weight of the module?
A8: The dimensions are 100 x 120 x 75 mm, and the weight is 0.25 kg.
