Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | AI930S (AI4H-Ex) |
| Article Number | 3KDE175511L9300 |
| Type | Analog Input |
| Number of Channels | 4 |
| Input Signal Type | 4…20 mA |
| HART Support | Yes |
| Power Redundancy | No |
| Intrinsic Safety | Yes, ATEX Zone 1 |
| Mechanics | S900 |
| Environmental Certification | CE, ISA-S71.04 G3 (Corrosive), RoHS, WEEE |
| Max Ambient Temperature | -20°C to +60°C |
| Max Relative Humidity | 93% ±3% at 40°C |
| Channel Isolation | Electrical isolation between input/bus and input/power |
| Power Supply Function | Supports 4…20 mA loop-powered 2-wire transmitters |
| Communication Protocol | PROFIBUS DP, HART support |
| Hot Swap | Supported |
| Hot Standby | Supported |
| Dimensions (L×W×H) | 150 × 75 × 50 mm |
| Weight | 0.45 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What input signals are supported by the ABB AI930 module?
A1: The module supports 4…20 mA current analog input, suitable for 2-wire loop-powered transmitters.
Q2: Does this module support the HART protocol?
A2: Yes, it supports HART communication, including cyclic HART variable transmission and HART command frame transfer.
Q3: In which hazardous areas can the AI930 module be installed?
A3: The module can be installed directly in Zone 1 hazardous areas and can connect to intrinsically safe field devices in Zone 2, Zone 1, or Zone 0.
Q4: Does the module support hot swap?
A4: Yes, it supports hot swap, allowing module replacement during system operation without powering down.
Q5: Is channel isolation provided in the AI930 module?
A5: Yes, electrical isolation is provided between input/bus and input/power, enhancing system safety.
Q6: What are the dimensions and weight of the module?
A6: The module measures 150 x 75 x 50 mm and weighs 0.45 kg.
Q7: What environmental conditions is the AI930 module suitable for?
A7: The module operates reliably at up to 93% relative humidity and temperatures from -20°C to +60°C, meeting industrial requirements.
Q8: Does the module provide self-diagnostic and fault detection features?
A8: Yes, the module features auto-diagnostics and can detect channel short circuits and open circuits, improving reliability.
