Technical Specifications
| Parameter | Description |
|---|---|
| Model | AI931 S900 I/O Analog Input Module |
| Article Number | 3KDE175511L9310 |
| Number of Channels | 4 |
| Input Signal Type | 4…20 mA (Passive, supports 0/4…20 mA) |
| HART Protocol | Yes |
| Redundancy | No |
| Intrinsic Safety | Yes |
| Mechanics | S900 |
| Installation Area | Suitable for Zone 1 hazardous locations |
| Certification | ATEX Zone 1, CE, RoHS, WEEE |
| Corrosive Resistance | ISA-S71.04 G3 |
| Relative Humidity | Max 93% (at 40°C, ±3%) |
| Operating Temperature | -20°C to 60°C |
| Overall Dimensions | 140 x 96 x 88 mm |
| Module Size | W20 x D104 x H104 mm |
| Weight | 0.6 kg (total), 0.13 kg (per module) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What input signals are supported by the ABB AI931 module?
A1: It supports 4 channels of 0/4…20 mA current input.
Q2: Does this module support the HART communication protocol?
A2: Yes, it supports HART communication, including HART frame and cyclic variables transmission.
Q3: Does the AI931 module provide redundancy?
A3: No, redundancy is not supported.
Q4: In which hazardous zones can this module be installed?
A4: It can be installed directly in Zone 1 and can connect intrinsically safe devices in Zone 2, Zone 1, or Zone 0.
Q5: What is the corrosion resistance of the module?
A5: The module is rated to ISA-S71.04 G3, suitable for corrosive environments.
Q6: What is the operating temperature range of the module?
A6: The operating temperature range is -20°C to 60°C.
Q7: What are the dimensions and weight of the module?
A7: The dimensions are 140 x 96 x 88 mm, and the weight is 0.6 kg.
Q8: Does the module support hot swap and online configuration?
A8: Yes, the module supports hot swap and online configuration, making maintenance and replacement convenient.
