Technical Specifications
| Property | Characteristic/Value |
|---|---|
| Size | 72 x 144 x 381 mm (2.82 x 5.67 x 15.0 in.) |
| Weight | 2.2 kg |
| Displays | 3 gas plasma bar graphs (200 segments for process variable and set point at 0.5% resolution, 100 segments for output at 1.0% resolution), 8-character, 14-segment, alphanumeric display |
| Bypass | Automatic entry or selected from faceplate |
| Communication | 5 or 40 kbaud RS-485 serial link to the controlling module through the termination unit |
| Mounting | Flush panel mounting |
| Supply Voltage | 21.6 VDC minimum, 27.0 VDC maximum |
| Power Consumption | 540 mA at 24 VDC |
| Analog Output – Current | 3 to 21 mA |
| Load Compliance | 600 Ω maximum |
| Inductance | 600 mH maximum |
| Accuracy | 2.0% of span at 25°C (77°F) |
| D/A Resolution | 8 bits |
| Analog Input – Voltage Range | +0.75 VDC to +5.25 VDC maximum |
| Analog Input – Impedance | >10 MΩ |
| Analog Input – Accuracy | 1.5% of span at 25°C (77°F) |
| A/D Resolution | 8 bit |
| Normal Mode Rejection | 75 dB minimum at 60 Hz |
| Common Mode Rejection | 90 dB minimum at 60 Hz |
| Common Mode Voltage | ±5 VDC maximum |
| Electric Drive | 100 mA maximum (sink or source) |
| Ambient Temperature | 5° to 40°C (41° to 104°F) |
| Humidity (Operating) | 20% to 80% (non-condensing) |
| Humidity (Storage) | 10% to 95% (non-condensing) |
| Atmospheric Pressure | Sea level to 3 km (1.86 mi) |
| Air Quality | Non-corrosive |
| Certification | CSA certified for use as process control equipment in an ordinary (non-hazardous) location |
FAQ
FAQ
-
Q: What is the size of the IISACO1 Analog Control Station?
-
A: The size is 72 x 144 x 381 mm (2.82 x 5.67 x 15.0 in.).
-
-
Q: How much does the IISACO1 Analog Control Station weigh?
-
A: The weight is 2.2 kg.
-
-
Q: What type of displays are used in the IISACO1?
-
A: The station features 3 gas plasma bar graphs and an 8-character, 14-segment alphanumeric display.
-
-
Q: How does the IISACO1 communicate with other modules?
-
A: It uses a 5 or 40 kbaud RS-485 serial link to communicate with the controlling module through the termination unit.
-
-
Q: What is the power consumption of the IISACO1?
-
A: The power consumption is 540 mA at 24 VDC.
-
-
Q: What is the analog output current range?
-
A: The analog output current range is 3 to 21 mA.
-
-
Q: What is the accuracy of the IISACO1’s analog input?
-
A: The accuracy is 1.5% of span at 25°C (77°F).
-
-
Q: What is the operating temperature range for the IISACO1?
-
A: The operating temperature range is 5° to 40°C (41° to 104°F).
-
