Technical Specifications
| Parameter | Specification |
|---|---|
| Product Number | 3BSE069449R1 (CI854BK01) |
| Communication Protocol | PROFIBUS DP-V1 |
| Operating Mode | Master |
| Number of Channels | 2 |
| Transmission Speed | 9.6 – 12,000 kbit/s |
| Line Redundancy | Yes |
| Module Redundancy | Yes |
| Hot Swap | Yes |
| Used with HI Controller | Yes |
| Max Units on CEX Bus | 12 |
| Connector | DB Female (9-pin) |
| Power Consumption | Typical 190 mA (24 V) |
| Operating Temperature | +5°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Pollution Degree | Degree 2 (IEC/EN61131-2) |
| Corrosion Protection | G3 (ISA 71.04) |
| Protection Class | IP20 (EN60529, IEC 529) |
| CE Certification | Yes |
| Marine Certifications | ABS, BV, DNV-GL, LR |
| RoHS Compliance | Complies with DIRECTIVE/2011/65/EU (EN 50581:2012) |
| WEEE Compliance | Complies with DIRECTIVE/2012/19/EU |
| Dimensions | Width 59 mm, Height 185 mm, Depth 127.5 mm |
| Weight | 700 g (including baseplate) |
FAQ
Frequently Asked Questions
Q1: What devices can the CI854B connect to?
A1: The CI854B connects remote I/O and fieldbus instruments via the PROFIBUS DP protocol, and it supports connecting PROFIBUS PA to the CI854B using the PROFIBUS linking device LD 800P.
Q2: Does the CI854B support redundancy features?
A2: Yes, the CI854B supports both line and module redundancy, allowing for PROFIBUS-DP master redundancy with two CI854B modules.
Q3: What is the maximum number of units supported by CI854B?
A3: The CI854B supports a maximum of 12 units on the CEX bus.
Q4: Is hot swapping supported on the CI854B?
A4: Yes, the CI854B supports hot swap functionality.
Q5: What is the operating temperature range for the CI854B?
A5: The CI854B operates within a temperature range of +5°C to +55°C.
Q6: What communication protocols does the CI854B support?
A6: The CI854B supports the PROFIBUS DP-V1 protocol and can operate in master mode.
Q7: What systems is the CI854B compatible with?
A7: The CI854B is compatible with System 800xA version 6.0.3.2 and onward, and Compact Control Builder version 6.0.0-2 and onward.
Q8: What is the protection class of the CI854B?
A8: The CI854B has an IP20 protection class, compliant with EN60529 and IEC 529 standards.
