Technical Specifications
| Parameter | Description |
|---|---|
| Model | CMRB-11C |
| Order Code | 3AUA0000054682 |
| Product Type | Brake Module |
| Application | For ABB ACS series drives |
| Max Braking Current | 11 A |
| Braking Resistor | External resistor required |
| Voltage Range | Matches drive voltage range |
| Mounting Type | Panel mounting |
| Operating Temp | -10°C to +50°C |
| Storage Temp | -40°C to +70°C |
| Protection Class | IP20 |
| Dimensions (L×W×H) | 100 × 70 × 30 mm |
| Weight | 0.15 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: Which ABB drives is the CMRB-11C brake module compatible with?
A1: It is mainly used with ABB ACS series drives such as ACS310 and ACS350. Refer to the drive manual for compatibility.
Q2: Does the CMRB-11C come with a braking resistor?
A2: No, an external resistor must be selected and installed according to the application requirements.
Q3: What should be noted during installation?
A3: Ensure proper ventilation, avoid close proximity to heat sources, and use insulated fasteners for safe mounting.
Q4: Will performance be affected if operating temperature exceeds limits?
A4: Yes, operating beyond -10°C to +50°C may degrade performance or damage the unit.
Q5: Is it normal for the module to heat up during operation?
A5: Moderate heat is normal. Excessive or persistent heating should prompt a review of the resistor sizing.
Q6: Does the module have built-in short circuit protection?
A6: No, external protection components are recommended to prevent fault conditions.
Q7: How can I verify if the brake module is functioning?
A7: Use the drive diagnostic interface or measure current/voltage to confirm brake module activity.
Q8: Can the CMRB-11C be replaced onsite if it fails?
A8: Yes, the module can be replaced onsite. Always ensure the power is off before servicing.
