Technical Specifications
| Category | Specification |
|---|---|
| Display | |
| Display Type | 10.1″ TFT-LCD, single-touch screen |
| Resolution | 1024 x 600 pixels |
| Brightness | 200 cd/m² |
| Color Depth | 65536 colors |
| Backlight Type | LED, typical lifetime 20,000 h @ 25°C |
| Touchscreen Type | Resistive, 4-wire, single-touch |
| Display Area Size | 224.32 mm x 126.88 mm |
| System Resources | |
| CPU | ARM Cortex-A8, 1 GHz |
| Operating System | Linux RT (Real-Time Linux) |
| Application Memory | Up to 60 MB for HMI projects |
| RAM | 512 MB |
| Flash Memory | 4 GB |
| Data Backup | Supercapacitor (approx. 72 h @ 25°C) |
| Real-Time Clock | < 100 ppm, backed by supercapacitor |
| Interfaces | |
| Ethernet | 1 x 10/100 Mbit |
| Serial Port | COM1 (RS-232/485/422), software configurable, D-sub |
| USB | 1 x USB 2.0 Host (max. 500 mA) |
| Power Supply | |
| Voltage | 24 V DC (18…32 V DC range) |
| Reverse Polarity | Yes |
| Terminal Connection | Removable 3-pin screw terminal |
| Max Current | 0.38 A |
| Environmental | |
| Operating Temp. | 0…50°C |
| Storage Temp. | -20…+70°C |
| Humidity | 5…85% RH, non-condensing |
| Air Pressure | >800 hPa / <2000 m |
| Front Protection | IP66 |
| Rear Protection | IP20 |
| Vibration Resistance | 5–9 Hz, 7 mm; 9–150 Hz, 1g (EN 60068-2-6) |
| Shock Resistance | ±50 g, 11 ms (EN 60068-2-27) |
| Mechanical Data | |
| Front Dimensions | 282 x 197 mm |
| Faceplate Depth | 6 mm |
| Housing Depth | 29 mm |
| Total Dimensions | 282 x 197 x 35 mm |
| Mounting Type | Panel mounting (landscape/portrait) |
| Cutout Size | 271 x 186 mm |
| Weight | 0.82 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: Does the CP610 support multi-touch input?
A1: No, it supports single-touch input only via a resistive touchscreen.
Q2: How long is the data retention time without power?
A2: With the internal supercapacitor, it retains data for approximately 72 hours at 25°C.
Q3: Can external memory cards be used?
A3: No, the CP610 does not support memory card slots.
Q4: Can CP610 be installed vertically?
A4: Yes, it supports both landscape and portrait mounting.
Q5: What is the operating temperature range?
A5: The unit operates between 0°C and 50°C.
Q6: What is the front panel protection rating?
A6: The front panel is rated IP66, suitable for harsh environments.
Q7: What communication interfaces are available?
A7: It includes 1 Ethernet port, 1 configurable serial port (RS-232/485/422), and 1 USB Host port.
Q8: How much application memory is available for HMI projects?
A8: Up to 60 MB is available for project storage.
