Technical Specifications
| Parameter | Specification |
|---|---|
| Display Type | 5.7” TFT color display |
| Resolution | 320 x 240 pixels |
| Touchscreen Type | Resistive touchscreen |
| Backlight | LED |
| Display Colors | 64K colors |
| User Flash Memory | 128 MB |
| Recipe Storage | Supported, limited by available flash |
| Power Input | 18…32 V DC |
| Rated Current | 0.65 A (@24 VDC) |
| Serial Interface | RS-232, RS-485, RS-422, software-configurable |
| Ethernet Ports | 2 x 10/100 Mbit/s with integrated switch |
| USB Ports | 2 x Host (1 x USB 2.0, 1 x USB 1.1) |
| SD Card Slot | Supported |
| Battery Type | Rechargeable lithium battery (non-user replaceable) |
| Real-Time Clock | Yes |
| Front Panel Rating | IP66 (when properly installed) |
| Operating Temp. | 0°C to +50°C |
| Storage Temp. | -20°C to +70°C |
| Weight | 1 kg |
| Dimensions (H x W x D) | 147 x 187 x 51 mm |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the power requirement for the CP630 panel?
A1: It requires a DC power supply in the range of 18 to 32 V, with a typical current of 0.65 A at 24 VDC.
Q2: How many Ethernet ports are available on CP630?
A2: The panel features two 10/100 Mbps Ethernet ports with integrated switching capability.
Q3: Does the CP630 support multilingual applications?
A3: Yes, it supports multilingual applications including Asian character sets.
Q4: Is a real-time clock available on the CP630?
A4: Yes, the panel includes a real-time clock with battery backup.
Q5: Is the brightness adjustable?
A5: Yes, the panel supports brightness adjustment and automatic backlight off settings.
Q6: Is SD card expansion supported?
A6: Yes, an SD card slot is included for external storage or program loading.
Q7: What is the protection rating of the CP630 panel?
A7: When properly mounted on a flat surface, the front panel is rated IP66.
Q8: Can the internal battery be replaced by the user?
A8: No, the battery is not user-replaceable. It is designed to support the internal RTC.
