Technical Specifications
| Parameter | Value |
|---|---|
| Module Type | Analog Input Module |
| Number of Channels | 16 channels |
| Input Signal Type | Standard 4-20 mA, 0-10 V signals |
| Power Supply | 18.5…30 V DC |
| Isolation Voltage | 3.7 kV (system connection to field) |
| Operating Temperature | -20°C ~ +60°C (horizontal mounting) |
| Relative Humidity | < 85%, non-condensing |
| Mounting | 35mm DIN rail |
| Dimensions | 170 x 105 x 32 mm |
| Weight | 0.12 kg |
| Protection Class | IP20 (after rack installation) |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many analog input channels does the DAI01 module support?
A1: It supports 16 analog input channels.
Q2: What types of input signals are supported?
A2: Standard 4-20 mA and 0-10 V analog signals are supported.
Q3: What is the required power supply voltage for the module?
A3: The power supply voltage range is 18.5 to 30 V DC.
Q4: What is the isolation voltage between system and field connections?
A4: The isolation voltage is 3.7 kV.
Q5: What is the operating temperature range of the module?
A5: The operating temperature range is -20°C to +60°C for horizontal mounting.
Q6: How is the module installed?
A6: It is installed on a standard 35mm DIN rail.
Q7: What are the dimensions and weight of the module?
A7: Dimensions are 170 x 105 x 32 mm, and the weight is 0.12 kg.
Q8: What is the protection class, and what environment is it suitable for?
A8: The protection class is IP20, suitable for installation inside control cabinets or non-hazardous areas.
