Technical Specifications Table
| Parameter | Details |
|---|---|
| Product Model | DI610 |
| Ordering Code | 3BHT300004R1 |
| Module Type | Digital Input Module |
| Number of Channels | 16 digital input channels |
| Input Voltage | 24 V DC (nominal) |
| Input Type | Opto-isolated, positive logic |
| Electrical Isolation | Optical isolation per channel |
| Input Current | Approx. 6 mA per channel |
| Status Indication | LED indicator per channel |
| Response Time | < 4 ms |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Mounting Type | DIN rail mounting |
| Communication Interface | Via system backplane bus |
| Power Supply | Supplied by system power |
| Dimensions (W×H×D) | 40 × 230 × 120 mm |
| Weight | 0.4 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: How many input channels does the DI610 module support?
A1: The module supports 16 digital input channels.
Q2: What type of input signal is accepted?
A2: It accepts 24V DC positive logic signals.
Q3: Does each input channel have an LED indicator?
A3: Yes, each channel is equipped with a dedicated LED status indicator.
Q4: Is input isolation provided per channel?
A4: Yes, each channel is optically isolated.
Q5: What is the mounting method for the module?
A5: The module supports DIN rail mounting.
Q6: What is the typical response time of the module?
A6: The typical response time is less than 4 milliseconds.
Q7: What are the physical dimensions of the module?
A7: The module dimensions are 40 × 230 × 120 mm.
Q8: What is the weight of the module?
A8: The module weighs 0.4 kg.
