Technical Specifications
| Parameter | Description |
|---|---|
| Model | DP640 |
| Order Code | 3BHT300057R1 |
| Input Type | S600 I/O Speed Meter Input |
| Max Input Frequency | 50 kHz |
| Input Current Range | ±13 mA |
| Input Voltage Options | 24 V DC or 5 V DC |
| Direction Detection | Supported (via second speed meter input) |
| Overspeed Trip Logic | Built-in |
| Trip Signal Output | Solid-state 24 V DC and Dry Contact 60 V DC |
| Isolation | Opto-isolated speed inputs and solid-state output |
| Dimensions | 252 x 273 x 40 mm |
| Weight | 1.33 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the maximum input frequency supported by the DP640 module?
A1: It supports a maximum speed meter input frequency of 50 kHz.
Q2: What are the input voltage and current specifications?
A2: The module accepts 24 V DC or 5 V DC input, with a current range of ±13 mA.
Q3: Can the module detect rotation direction?
A3: Yes, direction detection is enabled through a second speed meter input.
Q4: Does the module support overspeed trip functionality?
A4: Yes, the module includes built-in overspeed trip logic.
Q5: How is the trip signal output provided?
A5: The trip signal is output via 24 V DC solid-state or 60 V DC dry contact.
Q6: Are the inputs and outputs electrically isolated?
A6: All speed meter inputs and the solid-state output are opto-isolated.
Q7: What are the physical dimensions of the module?
A7: The dimensions are 252 x 273 x 40 mm.
Q8: What is the weight of the module?
A8: The module weighs 1.33 kg.
