Technical Specifications
| Parameter | Description |
|---|---|
| Model | DSTC 120 57520001-A |
| Function | RS232 C (V.24) asynchronous communication with support for short-range modem |
| Serial Ports | 2 independent serial ports |
| Connector X80 | 26-pin ribbon cable connector (for DSCA 114 asynchronous board) |
| Connector X90 | Screw terminal block for short-range modem (balanced current loop) |
| Connector X91, X92 | DB25 connectors for communication lines |
| Port A (X90) Output | AOPTOUTA (T+), BOPTOUTA (T-), AOPTINA (R+), BOPTINA (R-) |
| Port B (X90) Output | AOPTOUTB (T+), BOPTOUTB (T-), AOPTINB (R+), BOPTINB (R-) |
| Communication Standard | RS232 C (V.24), balanced current loop support |
| Default Communication Speed | 9600 Baud (host); 4800 Baud (keyboard) |
| Word Length | 8 bits |
| Parity | Even |
| Stop Bits | 1 bit |
| Dimensions | 200 × 80 × 40 mm |
| Weight | 0.125 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the purpose of the DSTC 120 unit?
A1: It provides RS232 asynchronous communication and supports short-range balanced current loop for serial data transfer.
Q2: How many serial ports are available on DSTC 120?
A2: It supports two independent serial ports.
Q3: What type of connectors does DSTC 120 offer?
A3: It includes a 26-pin ribbon connector (X80), screw terminal block (X90), and DB25 ports (X91, X92).
Q4: Is the DSTC 120 compatible with ABB MasterView 810/830?
A4: Yes, it is directly integrated into the MasterView 810/830 for serial communication.
Q5: What communication protocols are supported?
A5: DSTC 120 supports RS232 C (V.24) and balanced current loop protocols.
Q6: Can I use the DSTC 120 with TessEm software products?
A6: Yes, it is designed to connect TessEm systems with ABB equipment.
Q7: What are the default settings for host communication?
A7: 9600 Baud, 8 data bits, even parity, and 1 stop bit.
Q8: What is the weight and size of the DSTC 120?
A8: It measures 200 × 80 × 40 mm and weighs 0.125 kg.
