Technical Specifications
| Item | Specification |
|---|---|
| Product Model | GCU-02 |
| Manufacturer | ABB |
| Product Code | 3AXD50000028861 |
| Mounting Type | Panel mount / DIN rail (Frames A/B) |
| Power Supply | From drive DC bus (optional external power) |
| Communication | Ethernet E1/E2 (supports EtherCAT / POWERLINK) |
| Analog Inputs | 2 channels (X7) |
| Analog Output | 1 channel (X8) |
| Digital Inputs | 8 channels (X2 to X5) |
| Digital Outputs | 4 channels (X6) |
| Relay Output | 1 channel (X1) |
| Thermistor Input | Supported (X10) |
| External Power | Optional via X9 |
| Memory Unit | External MU module for parameter storage |
| Dimensions | 110 x 80 x 25 mm |
| Weight | 0.25 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the GCU-02 control unit?
A1: The GCU-02 is designed for MotiFlex e180 servo drives, managing control and communication functions.
Q2: Which fieldbus protocols are supported by GCU-02?
A2: It supports EtherCAT and Ethernet POWERLINK communication protocols.
Q3: Is an external auxiliary power supply required?
A3: No, it can operate from the drive’s DC bus; the external supply is optional.
Q4: How many digital I/Os are available on the GCU-02?
A4: It offers 8 digital inputs, 4 digital outputs, and 1 relay output.
Q5: Does the unit provide analog interfaces?
A5: Yes, it includes 2 analog inputs and 1 analog output for external signal processing.
Q6: Is thermistor connection supported?
A6: Yes, it is supported through the X10 interface for temperature monitoring.
Q7: Can the configuration of one GCU-02 be transferred to another?
A7: Yes, configurations can be transferred via the MU (Memory Unit) module.
Q8: How is fault diagnosis performed on GCU-02?
A8: Diagnostic can be carried out via drive status indicators and Mint WorkBench software.
