Technical Specifications
| Parameter | Value |
|---|---|
| Product Name | NGPS-13C Option Kit Power Supply Board |
| Manufacturer | ABB |
| Part Number | 3AUA0000033361 |
| Application | Power supply for ACS 600 MultiDrive modules |
| Compatible Frame Sizes | Frame B2 to B5, R6i to R12i |
| Mounting | Rear-wall and base mounting with air baffle |
| Power Supply Type | Auxiliary power board for internal control units |
| Cooling | Forced air cooling with cabinet ventilation |
| Operating Temperature | Up to 40°C |
| EMC Compliance | Requires metal shielding and grounding |
| Dimensions (L x W x H) | 130 x 100 x 75 mm |
| Weight | 0.6 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the NGPS-13C board?
A1: It supplies auxiliary power to internal control and communication circuits in the ACS 600 MultiDrive system.
Q2: Can the NGPS-13C be used with any frame size?
A2: No. It is intended for use within specific frame configurations, such as B2 to B5 and R6i to R12i.
Q3: Does the NGPS-13C require forced cooling?
A3: Yes. It relies on air circulation from the cabinet’s built-in fans. An air baffle is also necessary to avoid heat buildup.
Q4: Is EMC shielding mandatory during installation?
A4: Yes. Proper shielding, grounding, and use of conductive gasket materials are necessary for EMC compliance.
Q5: What is the recommended installation method?
A5: It should be mounted using M6 or M8 screws on the rear wall and base, with an air baffle to isolate hot air flow.
Q6: Are there any compatibility requirements for power voltage?
A6: Yes. Ensure the power board matches the cabinet’s rated voltage (230V or 115V) as per cooling fan specifications.
Q7: What precautions should be taken during wiring?
A7: Cable shielding must be 360° grounded at cabinet entries using conductive clamps and meshes to reduce EMI.
Q8: Is it necessary to install the NGPS-13C separately from main modules?
A8: No. It is designed to be integrated within the cabinet alongside other modules, but with proper airflow separation.
