Technical Specifications
| Parameter | Description |
|---|---|
| Product Model | SDCS-IOB-23 |
| Order Code | 3BSE005178R0001 |
| Type | Digital Connection Board |
| Platform | ABB DCS800 DC Drive System |
| I/O Interface | Interface for digital I/O signal connection |
| Installation | Inserted into control board or extension slot |
| Operating Voltage | 24V DC (from drive system logic supply) |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -40°C to +70°C |
| Mounting Method | Plug-in module (ESD precautions required) |
| Cooling Method | Natural convection |
| Dimensions (mm) | 233.5 × 97.5 × 18.5 mm |
| Weight (kg) | 0.35 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the SDCS-IOB-23?
A1: It serves to interface digital input/output signals within the ABB DCS800 drive system.
Q2: Can it be used with non-ABB systems?
A2: Not recommended. It is designed specifically for ABB DCS800 architecture.
Q3: Does it support hot-swapping?
A3: No. Power must be disconnected before installation or removal to avoid damage.
Q4: What are typical installation precautions?
A4: Use anti-static wristbands, avoid touching circuitry directly, and ensure proper slot engagement.
Q5: What types of signals does the module handle?
A5: Digital input/output signals with 24V DC levels, suitable for industrial switching applications.
Q6: Does it require a separate power supply?
A6: No. It receives power from the main controller or drive power system.
Q7: How to verify correct installation?
A7: Ensure the board is securely inserted; check signal status via the drive diagnostic interface.
Q8: What should be done if the board fails?
A8: Disconnect power, remove the board, inspect the pins and slot; replace with an identical module if necessary.
