Technical Specifications Table
| Parameter | Value |
|---|---|
| Module Type | SDCS-PIN-46 |
| Part Number | 3BSE004939R1503 |
| Power Supply | 24 V DC |
| Isolation Method | Optical Isolation |
| Interface | Works with control, I/O, and power modules |
| Purpose | Interface and isolation for DCS800 system |
| Dimensions | 257 × 200 × 15 mm |
| Weight | 0.38 kg |
| Mounting Type | Plug-in |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | Max 95%, non-condensing |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main function of the SDCS-PIN-46 module?
A1: It provides interface connectivity and electrical isolation within the DCS800 system.
Q2: Does the module offer electrical isolation?
A2: Yes, it features optical isolation to separate control and power circuits.
Q3: Can SDCS-PIN-46 be interchanged with other PIN series modules?
A3: It is not recommended. While in the same series, PIN-46, PIN-48, and PIN-5x have specific roles and should be used per DCS800 configuration.
Q4: How should the SDCS-PIN-46 be installed?
A4: It should be installed in the specified rack slot with proper grounding to prevent electrostatic damage.
Q5: What is the required power supply for the module?
A5: The module operates on 24 V DC power, typically provided by the system’s power module.
Q6: Does the module support hot-swapping?
A6: No. Power must be disconnected before inserting or removing the module to avoid equipment damage or injury.
Q7: Can the module be replaced individually in case of failure?
A7: Yes. It can be replaced independently without affecting other modules in the DCS800 system.
Q8: What are the ideal environmental conditions for operation?
A8: Best used in 0°C to +55°C with relative humidity below 95%, avoiding moisture and corrosive gases.
