Technical Specifications
| Category | Specification |
|---|---|
| Model | TC570 |
| Type | MasterFieldbus Connection Unit |
| Power Supply | +24 V DC |
| Mounting Method | 19-inch rack or wall-mounted |
| Communication | MasterFieldbus interface |
| Signal Type | Serial communication, relay output, system status input |
| Relay Output | Max 250V AC/DC, max 8A resistive load, open time ≤ 8ms |
| Baud Rate | Supports 2 Mbit/s and 375 kbit/s |
| Max Distance | Up to 3000 m (fiber), 25 m (twisted pair) |
| Protection | IP20 |
| Width | 482 mm (standard 19-inch) |
| Dimensions | 216 x 54 x 144 mm |
| Weight | 0.75 kg |
| Orientation | Vertical, in a well-ventilated area |
| Indicators | LED indicators for RUN, FAULT, and other statuses |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary function of TC570?
A1: TC570 acts as the master Fieldbus connection unit, enabling data communication between controllers and remote I/O via the MasterFieldbus network.
Q2: What communication speeds does TC570 support?
A2: It supports both 2 Mbit/s and 375 kbit/s.
Q3: What wiring media are compatible with TC570?
A3: It supports twisted pair, coaxial cable, and optical fiber.
Q4: Does TC570 support bus redundancy?
A4: Yes, it supports redundancy using dual communication modules to enhance system availability.
Q5: What is the maximum communication distance?
A5: Up to 3000 meters with optical fiber; typically 25 meters with cable.
Q6: What are the installation requirements for TC570?
A6: It must be mounted vertically in a well-ventilated space to prevent overheating.
Q7: How are external signals connected to TC570?
A7: Signals are connected through terminal blocks; supports discrete inputs and status signals.
Q8: Are there LED indicators on TC570?
A8: Yes, the front panel includes LEDs for operational and fault status indications.
