Technical Specifications
| Item | Specification |
|---|---|
| Model | 21000-16-05-00-055-03-02 |
| Material | Aluminum housing with 304 stainless steel sleeve |
| Operating Temperature | -51°C to +177°C for XL 8mm/11mm probes; -34°C to +177°C for NSv |
| Storage Temperature | -51°C to +177°C |
| Enclosure Rating | CSA Type 4, compliant with API 670 standard |
| Explosion-Proof Certification | CSA approved: Class I Div 1&2 (Groups C & D), Class II Div 1&2 (E–G) |
| Housing Body Diameter | 83.3 mm |
| Housing Body Length | 161.6 mm |
| Weight | 1.1 kg (without fittings) |
| Sleeve Length | Customizable, up to 742 mm (29.2 inches) |
| Mounting Threads | Options: 3/4-14 NPT, 1/2-14 BSP, 1-11½ NPT, 7/8-14 UNF-2A |
| Conduit Ports | Optional explosion-proof fittings or blank plugs |
| Supported Probes | Compatible with 3300 XL 8mm, 11mm, and NSv series reverse mount |
FAQ
Frequently Asked Questions (FAQ)
Q1: Is this housing suitable for hazardous areas?
A1: Yes, the 21000 series is CSA explosion-proof certified for Class I, II, and III divisions and groups.
Q2: What material is used for the housing?
A2: The 21000 housing is made from aluminum with a 304 stainless steel sleeve for durability and reduced weight.
Q3: Which probe types are supported?
A3: It supports Bently Nevada 3300 XL 8mm, 11mm, and NSv reverse mount probes.
Q4: What is the maximum probe sleeve length supported?
A4: Up to 742 mm (29.2 inches). For sleeves over 304 mm, additional support is recommended to reduce vibration.
Q5: Are explosion-proof fittings available?
A5: Yes, options include single or double 3/4-14 NPT fittings, reducers, and sealing grips. Must be specified during ordering.
Q6: What is the operating temperature range?
A6: The housing supports -51°C to +177°C (with minimum probe temp at -34°C for NSv).
Q7: How is the sleeve length determined?
A7: It depends on installation conditions. Ensure the probe lead is longer than the sleeve for proper function.
Q8: Is there a compact housing alternative?
A8: Yes, for tight spaces, the 164818 compact housing is available and compatible with the same probe types.
