Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 21000-16-05-00-105-03-02 |
| Housing Material | Aluminum Body, 304 Stainless Steel Sleeve |
| Operating Temperature | -51°C to +177°C (-60°F to +351°F) |
| Storage Temperature | -51°C to +177°C (-60°F to +351°F) |
| Probe Compatibility | 3300 XL 8mm Probe |
| Conduit Fittings (Option E) | One 3/4-14 NPT plug & One 3/4-14 to 1/2-14 NPT reducer |
| Mounting Thread (Option F) | 1/2-14 BSP |
| Probe Cable Length (Option B) | 0.5 m (20 in) |
| Standoff Adapter Length (Option C) | 1.5 in (38 mm) |
| Probe Penetration Length (Option D) | 105 = 10.5 in (267 mm) |
| Compliance | CSA Certified, API 670 Compliant |
| Environmental Rating | CSA Type 4, Explosion-proof |
| Housing Body Diameter | 83.3 mm |
| Weight | 1.1 kg |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the main material used in the 21000 housing assembly?
A1: The 21000 housing is made of aluminum with a 304 stainless steel probe sleeve.
Q2: What is the operating temperature range for the 21000 housing?
A2: It supports temperatures from -51°C to +177°C.
Q3: Is the 21000 assembly certified for use in hazardous environments?
A3: Yes, it is CSA certified as explosion-proof and compliant with API 670.
Q4: What type of probe does the 21000-16 variant use?
A4: It uses the 3300 XL 8mm reverse mount proximity probe.
Q5: Can the probe penetration length be customized?
A5: Yes, it can be customized in 0.1 in (3 mm) increments. This unit uses a 10.5 in penetration.
Q6: What fittings are included in the 21000-16-05-00-105-03-02 configuration?
A6: It includes a 3/4-14 NPT plug and a 3/4-14 to 1/2-14 NPT reducer.
Q7: What is the diameter and weight of the housing body?
A7: The diameter is 83.3 mm and the typical weight is 1.1 kg.
Q8: Is additional support required for longer sleeves?
A8: Yes, sleeves longer than 304 mm require added support to prevent resonance.
