Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 21000-16-10-00-061-03-02 |
| Housing Material | Aluminum housing with 304 stainless steel probe sleeve |
| Operating Temperature | -51°C to +177°C (-60°F to +351°F) |
| Storage Temperature | -51°C to +177°C (-60°F to +351°F) |
| Certifications | CSA Type 4, Explosion-proof for Class I Div 1 & 2 (C, D) |
| Environmental Compliance | RoHS Directive 2011/65/EU |
| Mounting Thread Option | 3/4-14 NPT (Option F: 02) |
| Probe Type | 3300 XL 8mm Reverse Mount |
| Cable Length | 1.0 m (39 in) (Option B: 10) |
| Standoff Adapter Length | 1.5 in (38 mm) (Option C: 15) |
| Probe Penetration Length | 6.1 in (155 mm) (Option D: 061) |
| Fitting Type | Explosion-proof: NPT plug + reducer + cable seal (Option E: 03) |
| Housing Body Diameter | 83.3 mm (3.28 in) |
| Housing Weight | 1.1 kg (2.4 lb) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of material is used in the 21000 series housing?
A1: The 21000 housing uses aluminum for the main body and 304 stainless steel for the probe sleeve.
Q2: Is this housing suitable for hazardous environments?
A2: Yes, it is CSA certified for explosion-proof applications in Class I, II, III hazardous areas.
Q3: What is the maximum operating temperature?
A3: The maximum operating temperature is 177°C (351°F).
Q4: What type of probe is installed in the 21000-16-10-00-061-03-02 configuration?
A4: It uses a 3300 XL 8mm reverse mount proximity probe.
Q5: What is the significance of the Option D: 061?
A5: It refers to a 6.1-inch (155 mm) probe penetration length.
Q6: Is additional support needed for longer sleeves?
A6: Yes, sleeves longer than 304 mm (12 in) require additional support to prevent resonance.
Q7: What kind of fittings are included in Option E: 03?
A7: It includes one NPT plug, one NPT reducer, and a cable seal grip with multiple grommet sizes.
Q8: Does this model comply with API 670?
A8: Yes, it complies with API 670 standard for externally mounted proximity probe housings.
