Technical Specifications
| Parameter | Description |
|---|---|
| Housing Body Diameter | 83.3 mm |
| Total Length (A+B+C+D+E, depending on options) | Up to 742 mm (depends on probe cable and penetration options) |
| Material | Aluminum body, 304 stainless steel sleeve |
| Weight | 1.1 kg (excluding fittings and accessories) |
| Temperature Range | -51°C to +177°C (for 3300 XL 8mm/11mm probes) |
| Supported Probe Types | 3300 XL 8mm, 3300 XL 11mm, 3300 NSv, 420 nuclear, etc. |
| Enclosure Rating | CSA Type 4, API 670 compliant, hazardous area approved |
| Max Probe Sleeve Length | 742 mm (with 1 meter probe cable, support required) |
| Mounting Threads (Options) | 3/4-14 NPT, 1-11 1/2 NPT, 1/2-14 BSP, 7/8-14 UNF-2A, etc. |
| Fittings (Options) | Multiple NPT explosion-proof fittings, reducers, cable grips, etc. |
FAQ
Frequently Asked Questions (FAQ)
Q1: What environments is the 21000 series probe housing suitable for?
A1: This series is designed for hazardous locations, CSA explosion-proof certified, and API 670 compliant for external probe mounting.
Q2: What is the main housing material of the 21000 assembly?
A2: The main body is aluminum alloy, with a 304 stainless steel probe sleeve.
Q3: Which probe models are supported by the 21000 housing?
A3: Supports 3300 XL 8mm, 3300 XL 11mm, 3300 NSv, and other Bently Nevada probes.
Q4: What is the maximum allowable probe sleeve length for the 21000 housing?
A4: Maximum is 742 mm (when using the 1 meter probe cable option); additional support is needed for long sleeves.
Q5: What are the standard dimensions and weight of the 21000 housing?
A5: The housing diameter is 83.3 mm; standard weight is 1.1 kg (excluding accessories).
Q6: What is the temperature operating range for the 21000 housing?
A6: -51°C to +177°C for both operation and storage (for supported probe types).
Q7: Does the housing have any enclosure rating or certification?
A7: Certified as CSA Type 4 enclosure, suitable for corrosive, humid, and hazardous applications.
Q8: How do I select the correct mounting thread and fittings?
A8: Choose from 3/4-14 NPT, 1-11 1/2 NPT, 1/2-14 BSP, etc., based on equipment requirements and select appropriate explosion-proof fittings and cable grips as needed.
