Technical Specifications
| Parameter | Value / Description |
|---|---|
| Housing Body Diameter | 83.3 mm |
| Housing Length | 161.6 mm |
| Material | Aluminum body, 304 stainless steel sleeve |
| Weight | 1.1 kg (without fittings) |
| Temperature Range | Operating/Storage: -51°C to +177°C |
| Enclosure Rating | CSA Type 4 |
| Explosion-Proof Rating | CSA certified, suitable for Class I, II, III, Division 1 & 2, Groups C, D, E, F, G |
| Compatible Probe Types | 3300 XL 8mm, 3300 XL 11mm, 3300 NSv |
| Probe Sleeve Length | Custom per order (must exceed probe lead length, support required above 304 mm) |
| Max Probe Sleeve+Penetration Length | 0.5 m probe: 343 mm; 1.0 m probe: 742 mm |
| Optional Accessories | Adapters, oil seals, supports, multiple thread choices |
| Safety Standards | Compliant with API 670 standard |
FAQ
Frequently Asked Questions (FAQ)
Q1: What environments is the 21000 housing suitable for?
A1: It is suitable for hazardous and high-temperature environments, compliant with CSA Type 4 and API 670, supporting various hazardous area ratings.
Q2: What is the main material of this housing?
A2: The 21000 housing uses an aluminum body with a 304 stainless steel sleeve for strength and corrosion resistance.
Q3: Which probe types are compatible with this housing?
A3: Compatible with Bently Nevada 3300 XL 8mm, 3300 XL 11mm, and 3300 NSv probes.
Q4: What is the operating temperature range?
A4: The operating and storage temperature range is -51°C to +177°C.
Q5: What are the housing dimensions and weight?
A5: The housing body diameter is 83.3 mm, length is 161.6 mm, and weight is 1.1 kg (without fittings).
Q6: How is the probe sleeve length determined?
A6: The sleeve length is customized based on installation requirements; it must exceed the probe lead length, and support is required for lengths above 304 mm.
Q7: What certifications and standards does this product meet?
A7: CSA explosion-proof certification, meets API 670 standards, suitable for various hazardous areas.
Q8: What optional fittings and accessories are available?
A8: Explosion-proof thread fittings, adapters, oil seals, and various mounting threads are available as options.
