Technical Specifications
| Parameter | Description |
|---|---|
| Model | Bently Nevada 21000-16-10-00-087-03-02 |
| Housing Material | Aluminum body with 304 stainless steel sleeve |
| Operating Temperature | -51°C to +177°C (-60°F to +351°F) |
| Storage Temperature | -51°C to +177°C (-60°F to +351°F) |
| Compatible Probes | 3300 XL 8mm, NSv, 11mm |
| Housing Body Diameter | 83.3 mm |
| Housing Body Length | 161.6 mm |
| Weight | 1.1 kg (without fittings) |
| Explosion Proof Rating | CSA certified: Class I Div 1 & 2, Class II Div 1 & 2, Class III |
| Enclosure Rating | CSA Type 4 |
| Mounting Thread Options | 3/4-14 NPT, 1/2-14 BSP, others |
| Conduit Ports | Threaded, optional fittings |
| Probe Sleeve Length | Custom, up to 742 mm (29.2 in) depending on probe cable |
| Recommended Sleeve Support | Required if sleeve > 304 mm (12 in) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of material is used for the housing?
A1: The 21000 series uses an aluminum housing with a 304 stainless steel sleeve for corrosion resistance and durability.
Q2: What is the operating temperature range for this housing assembly?
A2: The housing supports operation and storage between -51°C and +177°C (-60°F to +351°F).
Q3: Is this housing suitable for hazardous environments?
A3: Yes, the 21000 housing is CSA certified for explosion-proof use in Class I, II, and III hazardous areas.
Q4: What probe types are compatible with this housing?
A4: It supports reverse mount probes like the 3300 XL 8mm, 3300 NSv, and 3300 XL 11mm.
Q5: Does this housing require additional support for long probe sleeves?
A5: Yes, sleeve lengths over 304 mm (12 in) require support to avoid vibration-induced issues.
Q6: What is the diameter and weight of the housing body?
A6: The housing has a diameter of 83.3 mm and weighs approximately 1.1 kg without fittings.
Q7: Are CSA explosion-proof fittings required?
A7: Explosion-proof fittings are optional, but CSA-rated explosion-proof capability is only valid when specified fitting options are selected.
Q8: Can the probe cable length be customized?
A8: Yes, the probe cable length is selectable during ordering, with standard options ranging from 0.5 m to 1.0 m.
