Technical Specifications
| Item | Specification |
|---|---|
| Model Number | 21000-16-10-00-228-03-02 |
| Housing Material | Aluminum body with 304 stainless steel sleeve |
| Operating Temperature | -51°C to +177°C (based on probe type) |
| Storage Temperature | -51°C to +177°C |
| Housing Diameter | 83.3 mm |
| Overall Length | 161.6 mm (excluding probe and fittings) |
| Weight | 1.1 kg (typical, without fittings) |
| Mounting Thread Options | 3/4-14 NPT, 1/2-14 BSP, and others |
| Enclosure Rating | CSA certified Type 4 |
| Hazardous Area Approval | Class I Div 1 & 2 Groups C, D Class II Div 1 & 2 Groups E, F, G Class III |
| Probe Compatibility | 3300 XL 8mm, 11mm, NSv series |
| Probe Penetration Range | 25.4 mm to >300 mm (configurable) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What types of probes are compatible with the 21000 housing?
A1: It supports 3300 XL 8mm, 11mm, and 3300 NSv reverse mount probes.
Q2: Is it suitable for hazardous area use?
A2: Yes, the 21000 housing is CSA certified explosion-proof and supports Class I, II, and III areas.
Q3: What is the diameter of the housing?
A3: The housing body diameter is 83.3 mm.
Q4: What material is the housing made of?
A4: The 21000 housing is made of aluminum with a 304 stainless steel sleeve.
Q5: What is the operating temperature range?
A5: The operating range is -51°C to +177°C depending on the probe used.
Q6: What is the maximum probe penetration length supported?
A6: It supports up to 300 mm, and longer lengths require additional sleeve support.
Q7: Is this housing compliant with API standards?
A7: Yes, it complies with API 670 standard for externally mounted proximity probe housings.
Q8: Can I choose different thread and fitting options?
A8: Yes, multiple mounting thread and fitting configurations are available per ordering options.
