Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 21000-16-10-00-256-04-02 |
| Housing Material | Aluminum body with 304 stainless steel sleeve |
| Operating Temperature | -51°C to +177°C (-60°F to +351°F) |
| Storage Temperature | -51°C to +177°C (-60°F to +351°F) |
| Enclosure Rating | CSA Type 4 enclosure, explosion-proof (when applicable options) |
| Compliance | API 670 Compliant, RoHS Directive 2011/65/EU |
| Compatible Probes | 3300 XL 8mm, 11mm; 3300 NSv |
| Thread Options | 3/4-14 NPT, 1/2-14 BSP, etc. |
| Sleeve Length | Customizable: typically up to 742 mm (29.2 in) |
| Housing Body Diameter | 83.3 mm (3.28 in) |
| Weight | Approx. 1.1 kg (2.4 lb) |
FAQ
FAQ
Q1: What probe types are supported with the 21000 housing?
A1: It supports 3300 XL 8mm, 3300 XL 11mm, and 3300 NSv reverse mount proximity probes.
Q2: Is the 21000 housing explosion-proof?
A2: Yes, it is CSA-certified explosion-proof when ordered with specific fittings and configuration.
Q3: What is the maximum probe sleeve length supported?
A3: The maximum length can go up to 742 mm (29.2 inches) depending on the probe configuration.
Q4: What temperature range does the housing support?
A4: It supports -51°C to +177°C for both operating and storage conditions.
Q5: Can I use the housing in hazardous environments?
A5: Yes, the housing is rated for Class I, II, III Division 1 & 2 hazardous locations.
Q6: Is the housing compliant with API standards?
A6: Yes, it is fully compliant with API 670 for externally mounted proximity probe housings.
Q7: What materials are used in the construction of the 21000 housing?
A7: The housing body is made of aluminum, and the sleeve is 304 stainless steel.
Q8: Are there options for customizing probe penetration and sleeve length?
A8: Yes, both standoff adapter length (C) and probe penetration (D) can be customized per application needs.
