Technical Specifications
| Item | Specification |
|---|---|
| Housing Material | Aluminum body with 304 stainless steel sleeve |
| Certification | CSA explosion-proof, API 670 compliant |
| Enclosure Rating | CSA Type 4 enclosure |
| Operating Temp. | -51°C to +177°C (-60°F to +351°F) |
| Storage Temp. | -51°C to +177°C (-60°F to +351°F) |
| Probe Compatibility | 3300 XL 8mm, 3300 XL 11mm, 3300 NSv, etc. |
| Housing Diameter | 83.3 mm |
| Housing Length | 161.6 mm |
| Weight | 1.1 kg (without fittings) |
| Sleeve Length | Optional, up to 742 mm (for 1.0 m probe cable) |
| Mounting Thread | Options: 3/4-14 NPT, 1-11 1/2 NPT, 1/2-14 BSP |
| Max (C+D) Length | 0.5 m probe: 343 mm; 1.0 m probe: 742 mm |
| Suitable Areas | Hazardous (Class I Div 1/2 C/D, II Div 1/2 E/F/G, III) |
| Compliance | RoHS, CSA, API 670 |
| Protection Options | Optional seals, adapters, sleeve supports |
FAQ
Frequently Asked Questions (FAQ)
Q1: Which probe types are compatible with the 21000 series housing?
A1: It supports Bently Nevada 3300 XL 8mm, 3300 XL 11mm, and 3300 NSv reverse-mount probes.
Q2: What is the typical weight of the 21000 housing?
A2: The typical weight is 1.1 kg (without fittings).
Q3: What is the operating temperature range of the housing?
A3: The housing is designed for -51°C to +177°C, suitable for industrial applications.
Q4: What explosion-proof and safety certifications does the housing have?
A4: It is CSA explosion-proof certified, API 670 compliant, and RoHS compliant.
Q5: How do I select the correct sleeve and probe length?
A5: Sleeve length depends on the installation; maximum is 742 mm for 1.0 m probe. The probe lead must be longer than the sleeve.
Q6: What mounting thread options are available?
A6: 3/4-14 NPT, 1-11 1/2 NPT, and 1/2-14 BSP threads are available.
Q7: What hazardous areas is the 21000 series suitable for?
A7: It is suitable for Class I (C/D), Class II (E/F/G), and Class III hazardous areas.
Q8: How do I choose protective accessories?
A8: Select seal kits, adapters, and sleeve supports based on sleeve length and application; long sleeves require additional support to prevent vibration.
