Technical Specifications
| Item | Specification |
|---|---|
| Model | 21000-16-10-15-098-03-02 |
| Housing Material | Aluminum body with 304 stainless steel sleeve |
| Probe Compatibility | 3300 XL 8mm, 3300 XL 11mm, 3300 XL NSv, others |
| Temperature Range | Operating & Storage: -51°C to +177°C (-60°F to +351°F) |
| Explosion Proof | CSA Certified, Class I, II, III, Division 1 & 2, Groups C-G |
| Enclosure Rating | CSA Type 4, API 670 compliant |
| Housing Body Diameter | 83.3 mm (3.28 in) |
| Length (A) | 161.6 mm (6.36 in) |
| Maximum Probe Penetration (C+D) | 742 mm (29.2 in) (depends on cable and configuration) |
| Weight | 1.1 kg (2.4 lb), without fittings |
| Threaded Ports | 3/4-14 NPT, others optional |
| Fittings | Multiple explosion-proof fitting options available |
| Mounting Thread | As cast/3/4-14 NPT/other options |
| Sleeve Length | 38 mm – 742 mm (1.5 – 29.2 in), customizable |
| Certifications | RoHS, CSA, API 670 |
| Operating Environment | Hazardous area, outdoor, heavy industrial |
FAQ
FAQ
Q1: What is the housing material for the 21000 series?
A1: The housing uses aluminum for the body and 304 stainless steel for the sleeve.
Q2: What probes are compatible with the 21000-16-10-15-098-03-02 assembly?
A2: It supports 3300 XL 8mm, 3300 XL 11mm, 3300 XL NSv probes, among others.
Q3: What is the diameter and weight of the housing body?
A3: The housing body diameter is 83.3 mm, and the typical weight is 1.1 kg (without fittings).
Q4: Is this product certified for hazardous environments?
A4: Yes, it is CSA certified for use in Class I, II, III, Division 1 & 2, Groups C-G hazardous areas.
Q5: What is the maximum allowable probe penetration length?
A5: The maximum C+D dimension for probe penetration is 742 mm, depending on cable length and configuration.
Q6: What temperature range can the assembly withstand?
A6: It can operate and be stored between -51°C to +177°C (-60°F to +351°F).
Q7: Is this housing compliant with API 670?
A7: Yes, it fully complies with API 670 standards for externally mounted proximity probe housings.
Q8: Are different mounting and fitting options available?
A8: Yes, the assembly offers various threaded ports, mounting threads, and explosion-proof fitting configurations.
