Technical Specifications
| Parameter | Description |
|---|---|
| Housing Material | Aluminum body, 304 stainless steel sleeve |
| Housing Diameter | 83.3 mm |
| Length (excluding sleeve) | 161.6 mm |
| Weight | 1.1 kg |
| Temperature Range | -51°C to +177°C (-60°F to +351°F) (probe and storage) |
| Protection Level | CSA Type 4 (suitable for hazardous environments) |
| Compatible Probes | 3300 XL 8mm, 3300 XL 11mm, 3300 NSv, etc. |
| Sleeve Length | Customizable, up to 742 mm (29.2 in) |
| Threaded Ports | 3/4-14 NPT, 1/2-14 BSP, and others available |
| Certifications | API 670 compliant, RoHS certified, CSA explosion-proof |
FAQ
FAQ
Q1: What are the main application areas for the 21000 series housing?
A1: It is primarily used for external mounting of proximity probes on industrial machinery, especially in harsh or hazardous environments.
Q2: Which probe types are supported by this housing?
A2: Supports Bently Nevada 3300 XL 8mm, 3300 XL 11mm, and 3300 NSv series reverse-mount probes.
Q3: What environments is this housing suitable for?
A3: It is CSA Type 4 rated, suitable for explosive and hazardous areas, as well as dust and water protection requirements.
Q4: Are the housing and sleeve lengths customizable?
A4: Yes, multiple length options are available; sleeve lengths can be customized up to 742 mm to meet different installation needs.
Q5: What thread options are available for installation?
A5: Threaded ports include 3/4-14 NPT, 1/2-14 BSP, and other types, making it compatible with various piping or equipment interfaces.
Q6: What certifications does the product have?
A6: Certified for explosion-proof applications by CSA, RoHS compliant, and meets API 670 standard.
Q7: Is the housing material suitable for corrosive environments?
A7: The 21000 uses an aluminum body with a 304 stainless steel sleeve. For enhanced corrosion resistance, the 24701 stainless steel version is available.
Q8: What should be considered if the sleeve length exceeds a certain value?
A8: For sleeve lengths over 304 mm (12 in), it is recommended to add a sleeve support to avoid vibration or resonance issues.
