Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 21000-16-10-15-124-03-023 |
| Housing Body Material | Aluminum body with 304 stainless steel sleeve |
| Operating Temperature Range | -51°C to +177°C (-60°F to +351°F) |
| Storage Temperature Range | -51°C to +177°C (-60°F to +351°F) |
| Probe Compatibility | 3300 XL 8mm Reverse Mount Probes |
| Hazardous Location Rating | CSA Type 4, Class I/II/III, Divisions 1 & 2 |
| Environmental Compliance | RoHS Directive 2011/65/EU |
| Conduit Fittings | Option code 03: NPT plug, NPT reducer, cable seal grip |
| Mounting Thread | 3/4-14 NPT (Option code 02 required for CA version) |
| Housing Body Diameter | 83.3 mm |
| Housing Body Weight | 1.1 kg (without fittings) |
| Max Probe Sleeve Length | Up to 742 mm (with 1.0 m cable) |
| Standoff Adapter Length | 38 mm (Option C: 15 = 1.5 in) |
| Probe Penetration Length | 124 mm (Option D: 124 = 4.88 in) |
FAQ
FAQ
Q1: What material is used in the 21000 housing assembly?
A1: The 21000 housing uses an aluminum body with a 304 stainless steel sleeve.
Q2: What is the operating temperature range of this housing?
A2: The housing supports operation from -51°C to +177°C (-60°F to +351°F).
Q3: Is the housing suitable for hazardous environments?
A3: Yes, it is CSA certified for Class I, II, III Division 1 & 2 hazardous areas.
Q4: What probe type is compatible with this housing model?
A4: It supports the 3300 XL 8mm reverse mount proximity probes.
Q5: What type of mounting thread does the housing support?
A5: This model uses a 3/4-14 NPT thread, mandatory for explosion-proof applications.
Q6: What are the conduit fitting options included?
A6: Option 03 includes a 3/4-14 NPT plug, reducer, and cable seal grip.
Q7: How long can the probe sleeve be?
A7: The sleeve can be up to 742 mm long with a 1.0 meter probe cable.
Q8: How much does the housing weigh?
A8: The 21000 housing weighs approximately 1.1 kg without fittings.
