Technical Specifications
| Parameter | Description |
|---|---|
| Model | 21000-28-05-00-064-04-02 |
| Material | Aluminum housing with 304 stainless steel sleeve |
| Operating Temperature | -51°C to +177°C |
| Storage Temperature | -51°C to +177°C |
| Housing Body Diameter | 83.3 mm |
| Weight | 1.1 kg (typical, without fittings) |
| Max Sleeve Length | Up to 742 mm (for 1.0 m probe cable) |
| Mounting Thread | 3/4-14 NPT (required when Standoff Adapter ≠ 00) |
| Enclosure Rating | CSA Explosion-Proof Certified, Type 4 Enclosure, API 670 |
| Compatible Probe Types | 3300 XL 8mm, NSv, 11mm |
| Optional Fittings | Multiple NPT/BSP options available |
FAQ
Frequently Asked Questions (FAQ)
Q1: Is this housing explosion-proof?
A1: Yes, the 21000 series housing is CSA-certified for explosion-proof environments (Class I, II, III).
Q2: What types of probes are supported?
A2: It is compatible with 3300 XL 8mm, 11mm, and NSv proximity probes.
Q3: What is the housing body diameter?
A3: The housing body diameter is 83.3 mm.
Q4: What is the typical weight of the housing?
A4: It typically weighs 1.1 kg without any fittings.
Q5: What is the operating temperature range?
A5: The operating and storage range is -51°C to +177°C.
Q6: How long should the probe cable be?
A6: The probe cable must exceed the sleeve length. Maximum supported sleeve length is approximately 742 mm.
Q7: Is it flexible in mounting configurations?
A7: Yes, it offers various standoff adapter and thread mounting options.
Q8: Does it comply with API standards?
A8: Yes, it fully complies with API 670 standards for externally mounted proximity probes.
