Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 21000-33-10-00-070-04-02 |
| Housing Material | Aluminum body with 304 stainless steel sleeve |
| Operating Temperature Range | -51°C to +177°C (-60°F to +351°F) (for XL 8mm, 11mm, and NSv probes) |
| Storage Temperature Range | -51°C to +177°C (-60°F to +351°F) |
| Compatibility | 3300 XL 8mm, 11mm, NSv proximity probes |
| Sleeve Support Requirement | Required for sleeve lengths > 304 mm (12 inches) |
| Compliance | CSA Certified, RoHS Compliant, API 670 Compliant |
| Explosion Proof Rating | CSA Type 4 enclosure, Class I/II/III, Division 1 & 2, Groups C–G |
| Cable Entry Fittings | Configurable (explosion-proof NPT fittings or none) |
| Mounting Thread Options | As-cast / 3/4-14 NPT / 1/2-14 BSP / others |
| Dimensions (Housing Body Diameter) | 83.3 mm (3.28 inches) |
| Weight | 1.1 kg (2.4 lbs) |
FAQ
FAQ
Q1: What is the primary material of the 21000 housing assembly?
A1: It uses an aluminum housing with a 304 stainless steel probe sleeve.
Q2: What probe models are compatible with this housing?
A2: It supports 3300 XL 8mm, 3300 XL 11mm, and 3300 NSv reverse mount probes.
Q3: What is the maximum operating temperature?
A3: The housing supports probes operating up to +177°C.
Q4: Can it be used in hazardous environments?
A4: Yes, it is CSA-certified for Class I, II, III Div 1 & 2 Groups C-G and explosion-proof rated.
Q5: Is it necessary to use a sleeve support?
A5: Yes, if the sleeve length exceeds 304 mm (12 in), sleeve support is required.
Q6: What certifications does the 21000 housing comply with?
A6: CSA Type 4, RoHS 2011/65/EU, and API 670 standards.
Q7: Are mounting threads customizable?
A7: Yes, several thread options are available including 3/4-14 NPT and 1/2-14 BSP.
Q8: How heavy is the 21000 housing without accessories?
A8: The typical weight is approximately 1.1 kg.
