Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 330100-90-02 |
| System Components | 8 mm or 5 mm Probe + Extension Cable + Proximitor Sensor |
| Power Supply | -17.5 Vdc to -26 Vdc, max 12 mA |
| Linear Range | 2 mm (80 mils) |
| Recommended Gap Setting | 1.27 mm (50 mils) |
| Scale Factor | 7.87 mV/μm (200 mV/mil) ±6.5% |
| Frequency Response | 0 to 6.5 kHz, ±3 dB |
| Output Resistance | 50 Ω |
| Minimum Target Size | 15.2 mm diameter flat surface |
| Operating Temperature Range | Sensor: -51°C to +100°C Probe: up to +177°C |
| Storage Temperature | -51°C to +100°C |
| Relative Humidity | 100% condensing (with protected connectors) |
| Cable Capacitance | 69.9 pF/m typical |
| Total Length | 9.0 meters |
| Total Weight | 0.71 kg (1.6 lb) typical |
| Probe Weight | 323 g |
| Extension Cable Weight | 34 g/m |
| Sensor Weight | 255 g |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Certifications | CSA, BASEEFA/CENELEC, CE mark compliant |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary function of the 330100-90-02 Proximitor Sensor?
A1: It measures shaft vibration and position by detecting changes in the distance between the probe tip and a metallic surface.
Q2: Can the 330100 sensor be used with both 5 mm and 8 mm probes?
A2: Yes, it supports 3300 5 mm, 3300 8 mm, and 3300 XL 8 mm probes.
Q3: What is the recommended gap setting for accurate measurements?
A3: The recommended gap setting is 1.27 mm (50 mils).
Q4: What are the environmental limits of the sensor?
A4: Operating temperature is -51°C to +100°C, with 100% condensing humidity resistance when connectors are protected.
Q5: Is it suitable for hazardous environments?
A5: Yes, with appropriate barriers or isolators, it is certified for use in Class I, Division 1 and 2, and Zone 0/1/2 hazardous areas.
Q6: What is the length of the sensor system?
A6: The total length of this model is 9.0 meters.
Q7: Can the components be mixed from XL and non-XL series?
A7: Yes, but performance is limited to the non-XL specifications.
Q8: What material is the probe tip made of?
A8: It is made of polyphenylene sulfide (PPS), known for high temperature and chemical resistance.
