Technical Specifications
| Specification | Details |
|---|---|
| Total Length | 0.5 meters (1.6 feet) |
| Weight | 0.161 kg (0.355 lbs) |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 Stainless Steel (SST) |
| Probe Cable | 75Ω Triaxial, Fluoroethylene Propylene (FEP) Insulated |
| Tensile Strength | 330 N (75 lbf) probe case to probe lead |
| Maximum Rated Torque | 33.9 N•m (300 in•lbf) for standard forward-mounted probes |
| Operating Temperature Range | -52°C to +177°C (-62°F to +350°F) |
| Extended Temperature Range | -52°C to +218°C (-62°F to +425°F) for probe tip; -51°C to +260°C (-60°F to +500°F) for probe cable |
| Linear Range | 2 mm (80 mils), from approximately 0.25 mm (10 mils) to 2.3 mm (90 mils) |
| Nominal Probe DC Resistance | 7.45 ± 0.50 Ohms for 0.5 m probe length |
| Output Resistance | 50 Ω |
| Frequency Response | 0 to 10 kHz, +0, -3 dB, with up to 305 meters (1000 feet) of field wiring |
| Maximum Probe Pressure | Sealed differential pressure between the probe tip and case |
| Connector Material | Gold-plated Brass or Gold-plated Beryllium Copper |
| Connector-to-Connector Torque | Finger-tight (no special tools required) |
| Compliance | CE, RoHS, ATEX/IECEx, SIL 2, SIL 3 |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the maximum temperature the 3300 XL 8 mm probe can withstand?
A1: The probe can withstand an operating temperature of -52°C to +177°C (-62°F to +350°F) under standard conditions. For extended temperature range probes, the maximum temperature is +218°C (+425°F) for the probe tip and +260°C (+500°F) for the cable.
Q2: How do I install the connectors for this proximity probe?
A2: The connectors are designed to be finger-tightened. Simply twist the gold-plated connectors until they click into place, ensuring a secure connection. No special tools are required for installation.
Q3: Can this proximity probe be used in hazardous areas?
A3: Yes, the 3300 XL 8 mm proximity probe has certifications for use in hazardous environments, including ATEX/IECEx, and can be installed with intrinsic safety barriers or galvanic isolators in Zone 0 and Zone 2 areas.
Q4: What materials are compatible with this proximity probe?
A4: The probe is calibrated by default to AISI 4140 steel. Calibration to other materials can be requested.
Q5: What is the maximum cable length that can be used with the 3300 XL 8 mm probe?
A5: The system can support up to 305 meters (1000 feet) of field wiring, depending on the configuration.
Q6: What are the mechanical limitations for probe installation?
A6: The probe has a maximum recommended torque of 33.9 N•m (300 in•lbf) for standard forward-mounted probes. Ensure the thread engagement length does not exceed the industry standard to avoid issues during installation.
Q7: Is this probe compatible with older 3300 series probes and systems?
A7: Yes, the 3300 XL 8 mm probe and components are backward compatible with non-XL 3300 5 mm and 8 mm probes, ensuring easy integration with older systems.
Q8: What is the recommended gap setting for measuring radial vibration?
A8: The recommended gap setting for radial vibration measurements is -9 Vdc, which corresponds to approximately 1.27 mm (50 mils) from the target.
