Technical Specifications
| Item | Description |
|---|---|
| Probe Tip Diameter | 8 mm |
| Total Length | 1.0 meter |
| Weight | 0.323 kg |
| Probe Material | PPS tip, Stainless Steel case |
| Cable Type | 75Ω triaxial, FEP insulated |
| Power Supply | -17.5 to -26 VDC, 12 mA typical |
| Output Resistance | 50 Ω |
| Power Supply Sensitivity | <2 mV per volt of supply variation |
| Linear Measurement Range | 0.25 mm to 2.3 mm (10 to 90 mils) |
| Recommended Gap Setting | 1.27 mm (50 mils), corresponding to -9 VDC |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) ±5% |
| Minimum Target Size | 15.2 mm diameter |
| Recommended Shaft Diameter | Min: 50.8 mm; Recommended: 76.2 mm |
| Tensile Strength | 330 N (probe housing to cable) |
| Operating Temperature (Probe) | -52°C to +177°C |
| Storage Temperature (Probe) | -52°C to +177°C |
| Humidity Effect | <3% ASF change under 93% RH (56 days) |
| Minimum Cable Bend Radius | 25.4 mm |
| Thread Specification | M10 x 1 |
| Max Thread Engagement | 15 mm |
| Cable Max Diameter | 3.94 mm (FluidLoc), 9.5 mm with armor |
FAQ
Frequently Asked Questions (FAQ)
Q1: What kind of equipment is this probe designed for?
A1: It is primarily used for fluid-film bearing machines to measure vibration, position, and Keyphasor signals.
Q2: Can it be used in high-temperature environments?
A2: Yes. The standard version withstands up to 177°C. ETR versions support up to 218°C for the probe and 260°C for cables.
Q3: Do I need to calibrate probe, extension cable, and Proximitor sensor as a set?
A3: No, all 3300 XL 8 mm components are fully interchangeable without individual calibration.
Q4: What is the minimum shaft diameter supported?
A4: The minimum supported shaft diameter is 50.8 mm; 76.2 mm is recommended to reduce cross-talk.
Q5: Is the product compliant with API 670?
A5: Yes, the 5-meter standard system meets API 670 for mechanical configuration, linearity, and accuracy.
Q6: What is the linear range of the probe?
A6: The linear response range is from 0.25 mm to 2.3 mm (10 to 90 mils) from the probe tip to the target.
Q7: Are any special tools needed to install the connectors?
A7: No, the ClickLoc connectors are finger-tight and provide a “click” when properly secured.
Q8: Is this product suitable for hazardous or offshore areas?
A8: Yes, it has CSA, ATEX, and IECEx certifications for Zone 0/1/2 hazardous locations.
