📌 Technical Specifications
| Parameter | Description |
|---|---|
| Model Number | 330104-00-08-10-01-05 |
| Probe Diameter | 8 mm |
| Thread Type | M10 x 1 |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Probe Body Material | Stainless Steel AISI 303 / 304 |
| Cable Type | 75Ω triaxial FEP insulated |
| Total Length | 1.0 meter |
| Weight | Approx. 0.323 kg (probe only) |
| Pull Strength | 330 N (probe case to lead), 270 N (lead to extension cable) |
| Installation Torque (Recommended) | 7.5 N·m (66 in·lbf) |
| Minimum Cable Bend Radius | 25.4 mm |
| Operating Temperature (Probe) | -52°C to +177°C |
| Storage Temperature (Probe) | -52°C to +177°C |
| Humidity Tolerance | <3% change in ASF @ 93% RH per IEC 68-2-3 (56 days) |
| Linear Range | 0.25 mm to 2.3 mm (10 to 90 mils) |
| Recommended Gap | 1.27 mm (50 mils) |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) ±5% (1 m / 5 m system) |
| Deviation from Best Fit Line | < ±0.025 mm (1 mil) for 1 m and 5 m systems |
| Cable Capacitance | 69.9 pF/m |
| Output Resistance | 50 Ω |
| Output Voltage | Proportional to probe-target distance |
| Minimum Target Size | 15.2 mm (flat surface) |
| Recommended Minimum Shaft Diameter | 76.2 mm |
FAQ
❓ Frequently Asked Questions (FAQ)
Q1: What does this proximity probe measure?
A1: It measures both static shaft position and dynamic shaft vibration (radial and axial).
Q2: Is this probe compatible with older Bently Nevada 3300 series systems?
A2: Yes, it is fully compatible with non-XL 3300 5 mm and 8 mm system components.
Q3: Do the components of this system need to be calibrated together?
A3: No. All 3300 XL components are pre-calibrated at the factory and support full interchangeability.
Q4: Can this probe be used in high-temperature environments?
A4: Yes. The standard probe supports up to +177°C. Extended Temperature Range (ETR) versions support up to +218°C for the probe and +260°C for the cable.
Q5: Is the probe suitable for high-speed rotating equipment like turbines or compressors?
A5: Yes. It supports a frequency response up to 10 kHz and is suitable for machinery vibration monitoring.
Q6: Does the cable prevent oil or fluid leakage?
A6: Yes. The optional FluidLoc cable design prevents leakage of fluids through the cable interior.
Q7: Are special tools required for installing the connectors?
A7: No. The ClickLoc gold-plated connectors are finger-tight and do not require tools.
Q8: Is this probe certified for use in hazardous areas (e.g., Zone 0, Zone 1, Zone 2)?
A8: Yes. It meets CSA, ATEX, and IECEx certifications for use in Class I, Division 2 and Zones 0, 1, and 2 environments.
