Technical Specifications
| Parameter | Specification |
|---|---|
| Total Length | 1.0 meter |
| Weight | 0.161 kg |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| Probe Cable Specifications | 75Ω triaxial, fluoroethylene propylene (FEP) insulated |
| Maximum Rated Torque | 22.6 N•m (200 in•lbf) |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Nominal Probe DC Resistance | 7.59 ± 0.50 Ω at 1.0 meter |
| Nominal Extension Cable DC Resistance | 0.66 ± 0.10 Ω at 3.0 meters |
| Capacitance | 69.9 pF/m (21.3 pF/ft) typical |
| Linear Range | 2 mm (80 mils), from 0.25 mm (10 mils) to 2.3 mm (90 mils) |
| Operating Temperature Range | -52°C to +177°C (-62°F to +350°F) |
| Extended Temperature Range | -52°C to +218°C (-62°F to +425°F) for the probe tip |
| Frequency Response | 0 to 10 kHz, +0, -3 dB |
| Minimum Target Size | 15.2 mm (0.6 in) diameter (flat target) |
| Shaft Diameter | Minimum 50.8 mm (2 in), Recommended 76.2 mm (3 in) |
| Environmental Limits | Humidity: Less than 3% change in Average Scale Factor (ASF) at 93% humidity |
| System Weight (Typical) | 0.7 kg (1.5 lb) |
FAQ
FAQ
Q1: What is the maximum operating temperature for the 3300 XL 8 mm Reverse Mount Probe?
A1: The standard probe operates between -52°C to +177°C (-62°F to +350°F). An extended temperature range probe can operate up to +218°C (+425°F) for the probe tip.
Q2: What is the typical frequency response of the 3300 XL 8 mm system?
A2: The system has a frequency response of 0 to 10 kHz, with a +0, -3 dB range.
Q3: What is the minimum target size required for the probe?
A3: The minimum target size is 15.2 mm (0.6 in) in diameter for a flat target.
Q4: What is the weight of the probe?
A4: The probe has a weight of approximately 0.161 kg.
Q5: How do I install the probe’s connectors?
A5: The probe connectors are gold-plated and use the ClickLoc locking mechanism. Finger-tight torque is sufficient for installation, and no special tools are needed.
Q6: What is the cable bend radius for this probe system?
A6: The minimum cable bend radius is 25.4 mm (1.0 in).
Q7: What is the recommended gap setting for radial vibration measurements?
A7: The recommended gap setting is -9 Vdc, which is approximately 1.27 mm (50 mils).
Q8: Can the 3300 XL 8 mm system be used in hazardous environments?
A8: Yes, the 3300 XL 8 mm system has hazardous area approvals for use in Class I, Zone 0 and 2, and other certified areas, including ATEX, IECEx, and CSA certifications.
