Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | 330130-045-02-05 |
| Product Type | Extension Cable (Standard) |
| Cable Length | 4.5 meters / 14.8 feet |
| Cable Material | 75Ω triaxial, FEP insulation |
| Electrical Connector | ClickLoc metallic connectors, gold-plated contacts |
| Capacitance | 69.9 pF/m (21.3 pF/ft) |
| Center Conductor RCORE | 0.99 ± 0.15 Ω |
| Jacket Conductor RJACKET | 0.30 ± 0.06 Ω |
| Minimum Bend Radius | 25.4 mm (1 inch) |
| Operating Temperature | -52°C to +177°C (standard), up to +260°C (ETR version) |
| Environmental Sealing | Recommended with connector protectors |
| Weight (Typical) | 0.153 kg (cable only) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of cable is the 330130-045-02-05?
A1: It is a standard extension cable used in Bently Nevada’s 3300 XL proximity transducer system, measuring 4.5 meters in length.
Q2: What is the operating temperature range?
A2: The standard cable supports -52°C to +177°C. The extended temperature range (ETR) version supports up to +260°C.
Q3: Which probes is this cable compatible with?
A3: It is compatible with both 3300 XL 8 mm and non-XL 5 mm/8 mm probes and works with corresponding Proximitor sensors.
Q4: Can this cable be used with non-XL systems?
A4: Yes, it is backward compatible, but system performance will be limited to non-XL specifications.
Q5: Is a special tool required for installation?
A5: No, the ClickLoc connector is designed for finger-tight installation, no tools needed.
Q6: Is the cable resistant to oil leakage?
A6: Yes, the optional FluidLoc version prevents oil or fluid from leaking through the cable.
Q7: Can it operate in high humidity environments?
A7: Yes, it has been tested under 93% relative humidity with minimal impact on electrical performance.
Q8: What is the cable weight? Is it suitable for mobile systems?
A8: The cable weighs 0.153 kg, making it lightweight and suitable for confined or dynamic installations.
