Technical Specifications
| Parameter | Value |
|---|---|
| Model Number | 330130-080-00-05 |
| Product Name | 3300 XL Standard Extension Cable |
| Cable Length | 8.0 meters |
| Cable Weight | 0.272 kg |
| Cable Type | 75Ω triaxial FEP insulated standard |
| Cable Capacitance | 69.9 pF/m (typical) |
| Minimum Bend Radius | 25.4 mm |
| Core Resistance (RCORE) | 1.76 ± 0.26 ohms |
| Jacket Resistance | 0.53 ± 0.11 ohms |
| Connector Type | Gold-plated ClickLoc, anti-loosening |
| Operating Temperature | -52°C to +177°C |
| Storage Temperature | -52°C to +177°C |
| Recommended Environment | Industrial grade, vibration monitoring |
| Cable Material | FEP insulation, available armored/non-armored |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the primary use of the 330130-080-00-05 cable?
A1: It is used in Bently Nevada’s 3300 XL proximity transducer systems to connect the probe to the Proximitor Sensor.
Q2: Can it be used with non-XL series components?
A2: Yes, but system performance will be limited to non-XL component specifications.
Q3: Is an armored version available?
A3: Yes, both armored and non-armored versions are available for selection.
Q4: Does it support high temperature environments?
A4: The standard version supports up to +177°C. For higher temperatures, use the ETR variant.
Q5: Are special tools required for the connectors?
A5: No special tools are needed. The ClickLoc connector locks securely with hand-tightening.
Q6: Can the connectors be replaced in the field?
A6: Yes, Bently provides connector replacement kits and necessary tools.
Q7: What is the maximum cable length available?
A7: For this model, up to 8.5 meters. It must be matched with the probe length to equal total system length.
Q8: Is the cable leak-resistant?
A8: Yes, optional FluidLoc cables prevent oil or fluid ingress inside the cable.
