Technical Specifications
| Parameter | Value |
|---|---|
| Cable Length | 8.5 meters |
| Weight | 0.289 kg |
| Extension Cable Material | 75Ω triaxial, FEP insulated |
| Resistance (RCORE) | 1.87 ± 0.28 Ω (at 8.5 meters) |
| Resistance (RJACKET) | 0.56 ± 0.11 Ω (at 8.5 meters) |
| Capacitance | 69.9 pF/m (typical) |
| Minimum Cable Bend Radius | 25.4 mm (1.0 in) |
| Connector Type | Gold-plated ClickLoc connectors |
| Temperature Range | -52°C to +177°C (-62°F to +350°F) |
| Maximum Connector Torque | 0.565 N•m (5 in•lbf) |
FAQ
FAQ (Frequently Asked Questions)
Q1: What is the length of the 3300 XL Standard Extension Cable?
A1: The 3300 XL Standard Extension Cable is 8.5 meters in length.
Q2: What is the weight of the cable?
A2: The weight of the 3300 XL Standard Extension Cable is 0.289 kg.
Q3: What material is used for the cable insulation?
A3: The extension cable is made of 75Ω triaxial cable with FEP insulation.
Q4: What is the resistance of the extension cable?
A4: The resistance (RCORE) of the extension cable is 1.87 ± 0.28 Ω for an 8.5-meter length.
Q5: What is the minimum bend radius for the cable?
A5: The minimum bend radius for the 3300 XL Standard Extension Cable is 25.4 mm (1.0 in).
Q6: What is the connector type used for the extension cable?
A6: The extension cable uses gold-plated ClickLoc connectors for secure and easy connections.
Q7: What is the temperature range for the cable’s operation?
A7: The operating temperature range for the cable is from -52°C to +177°C (-62°F to +350°F).
Q8: Is the 3300 XL Standard Extension Cable compatible with other components?
A8: Yes, the 3300 XL Standard Extension Cable is fully compatible with the 3300 XL probe and Proximitor sensor system components, ensuring seamless interchangeability.
