Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 330180-52-CN |
| System Length | 5.0 meters (Total system includes probe + extension cable + sensor) |
| Total System Weight | 0.7 kg (1.54 lb) |
| Proximitor Sensor Weight | 246 g |
| Probe Weight | 323 g/m |
| Extension Cable Weight | 34 g/m (non-armored), 103 g/m (armored) |
| Power Supply | -17.5 Vdc to -26 Vdc, 12 mA max |
| Linear Range | 0.25 mm to 2.3 mm (10 to 90 mils) |
| Recommended Gap | 1.27 mm (50 mils) |
| ISF (5m system) | 7.87 V/mm ±5% |
| DSL (5m system) | ±0.025 mm (±1 mil) |
| Frequency Response | 0 to 10 kHz, +0/-3 dB |
| Operating Temp (Sensor) | -52°C to +100°C |
| Operating Temp (Probe) | -52°C to +177°C |
| Operating Temp (Cable) | -52°C to +177°C (standard), up to +260°C (ETR) |
| Humidity Tolerance | ≤3% deviation in 93% RH (IEC 68-2-3 standard) |
| Minimum Target Diameter | 15.2 mm (0.6 in) |
| Minimum Shaft Diameter | 50.8 mm recommended minimum 76.2 mm |
| Output Resistance | 50 Ω |
| Connector Type | ClickLoc gold-plated, finger-tight lock |
| Material (Probe Case) | AISI 303 or 304 stainless steel |
| Material (Sensor Housing) | Aluminum |
FAQ
FAQ
Q1: What is the total length and weight of the 330180-52-CN system?
A1: The total length is 5.0 meters and the weight is approximately 0.246 kg for the Proximitor Sensor.
Q2: What power supply is required for the sensor?
A2: It requires a DC power supply between -17.5 Vdc and -26 Vdc, with a typical current consumption of 12 mA.
Q3: What is the linear measurement range of this sensor?
A3: The linear range is from 0.25 mm to 2.3 mm (10 mils to 90 mils).
Q4: What is the recommended installation gap for vibration measurements?
A4: The recommended gap is approximately 1.27 mm (50 mils), corresponding to -9 Vdc.
Q5: Is the 330180-52-CN sensor suitable for high-temperature environments?
A5: Yes, it operates from -52°C to +100°C, and can work with probes and cables rated up to +260°C (ETR versions).
Q6: Can this sensor be used in hazardous areas?
A6: Yes, it is certified for use in Class I, Zone 0 and Zone 2 hazardous areas with appropriate barriers.
Q7: What is the frequency response range of this sensor system?
A7: The frequency response is from 0 to 10 kHz with ±3 dB accuracy.
Q8: Are the connectors tool-free for field installation?
A8: Yes, ClickLoc connectors are finger-tightened and click-locked, requiring no tools.
