Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 330180-91-CN |
| Total System Length | 9.0 meters |
| Weight (Typical) | 0.246 kg (Proximitor Sensor only) |
| Probe Type | Non-contacting Eddy Current 3300 XL 8 mm Probe |
| Power Supply Requirement | -17.5 Vdc to -26 Vdc, max current 12 mA |
| Output Resistance | 50 Ω |
| Recommended Gap Voltage | -9 Vdc (approx. 1.27 mm or 50 mils) |
| Linear Range | 0.25 mm to 2.3 mm (10 mils to 90 mils) |
| Scale Factor | 7.87 V/mm (200 mV/mil) ±6.5% |
| Frequency Response | 0 to 10 kHz (+0/-3 dB) |
| Minimum Target Size | 15.2 mm |
| Recommended Shaft Size | 76.2 mm minimum |
| Probe Materials | PPS Tip, SST Stainless Steel Case |
| Cable Type | 75Ω triaxial FEP or PFA insulated |
| Min Cable Bend Radius | 25.4 mm (1.0 in) |
| Operating Temp (Sensor) | -52°C to +100°C |
| Storage Temp (Sensor) | -52°C to +105°C |
| Operating Temp (Probe) | Std: -52°C to +177°C; ETR: -52°C to +218°C |
| Certifications | CSA, ATEX, IECEx, CE, SIL2/SIL3 |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of machines is this sensor suitable for?
A1: It is mainly used for vibration and position monitoring on fluid-film bearing machines and also supports Keyphasor and speed measurements.
Q2: Does it meet API 670 standards?
A2: Yes, the standard 3300 XL 8 mm system complies fully with API 670 for mechanical configuration, linear range, accuracy, and temperature stability.
Q3: Are system components interchangeable?
A3: Yes. All 3300 XL series probes, extension cables, and Proximitor sensors are fully interchangeable without the need for re-calibration.
Q4: Are there temperature limitations for probes and cables?
A4: Standard probes operate up to 177°C; extended temperature probes up to 218°C, and cables up to 260°C.
Q5: Is the sensor immune to electrical interference?
A5: Yes. It features excellent RFI/EMI immunity, suitable for fiberglass enclosures and high-interference areas.
Q6: Are FluidLoc cables available?
A6: Yes, FluidLoc cables can be ordered to prevent fluid leakage through the cable interior.
Q7: What are the minimum target and shaft diameters?
A7: Minimum target size is 15.2 mm; minimum recommended shaft diameter is 76.2 mm to avoid cross-talk.
Q8: Are any special tools required for installation?
A8: No special tools are needed; the SpringLoc terminal strips allow quick and reliable hand wiring.
