Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 330180-A51-B00 |
| System Length | 5.0 meters |
| Application | Vibration and position measurement on fluid-film bearing machines |
| Power Supply Requirement | -17.5 Vdc to -26 Vdc, max 12 mA |
| Output Resistance | 50 Ω |
| Linear Range | 2.0 mm (80 mils), typical from 0.25 mm to 2.3 mm |
| Recommended Gap Voltage | -9 Vdc (approx. 1.27 mm or 50 mils) |
| Incremental Scale Factor (5m system) | 7.87 V/mm (200 mV/mil) ±5% |
| Frequency Response | 0 to 10 kHz (+0/-3 dB with up to 305m field wiring) |
| Minimum Target Size | 15.2 mm (0.6 in) |
| Minimum Shaft Diameter | 50.8 mm (2 in), Recommended: 76.2 mm (3 in) |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | Stainless Steel (AISI 303 or 304) |
| Probe Cable Type | 75Ω triaxial, FEP insulated |
| Connector Type | ClickLoc, gold-plated |
| Sensor Housing Material | Aluminum A308 |
| Extension Cable Capacitance | 69.9 pF/m |
| Operating Temperature (Probe) | -52°C to +177°C |
| Operating Temperature (Sensor) | -52°C to +100°C |
| Storage Temperature (Sensor) | -52°C to +105°C |
| Relative Humidity (Probe) | <3% change in ASF after 56 days at 93% RH |
| Total Length | 5.0 meters |
| Weight | 0.246 kg (Sensor only); approx. 0.7 kg for full system |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the total length of the 330180-A51-B00 system?
A1: The total system length is 5.0 meters, including probe, extension cable, and sensor.
Q2: What type of output does this Proximitor Sensor provide?
A2: It provides a voltage output directly proportional to the distance between the probe tip and the observed target surface.
Q3: Is the sensor suitable for use in hazardous environments?
A3: Yes, it has ATEX, IECEx, CSA, and UL approvals for Class I, Zone 0/2 and Division 2 areas.
Q4: What is the recommended shaft diameter for optimal performance?
A4: A shaft diameter of at least 76.2 mm (3 in) is recommended.
Q5: Can the sensor operate in high humidity environments?
A5: Yes, it shows less than a 3% change in scale factor after testing at 93% RH for 56 days.
Q6: What materials are used for the probe tip and housing?
A6: The probe tip is made of PPS plastic, and the housing is stainless steel (AISI 303 or 304).
Q7: Does the sensor require special mounting tools?
A7: No, ClickLoc connectors are finger-tight and require no special tools.
Q8: What is the expected performance over the temperature range?
A8: Over –35°C to +120°C probe temp and 0°C to +45°C sensor/cable temp, ISF stays within ±10%.
