Technical Specifications Table
| Item | Specification |
|---|---|
| Sensitivity | 3.94 mV/mm/s (100 mV/in/s) ±5% |
| Frequency Response | 4.5 Hz to 5 kHz (±3 dB), 6 Hz to 2.5 kHz (±0.9 dB) |
| Temperature Sensitivity | -14% to +7.5% typical |
| Velocity Range | 1270 mm/s (50 in/s) peak |
| Transverse Sensitivity | Less than 5% of axial sensitivity |
| Amplitude Linearity | ±2% up to 152 mm/s (6 in/s) peak |
| Mounted Resonant Freq. | Greater than 12 kHz |
| Output Bias Voltage | -12 VDC ±3.0 V (ref. to Pin A) |
| Dynamic Output Impedance | Less than 2400 Ω |
| Broadband Noise Floor | 0.004 mm/s (160 μin/s) rms nominal |
| Grounding | Case isolated |
| Max Cable Length | 305 meters (1000 feet) without signal degradation |
| Operating Temperature | -55°C to +121°C (-67°F to +250°F) |
| Shock Survivability | Up to 5,000 g peak |
| Relative Humidity | Up to 100%, non-submerged, hermetically sealed case |
| Base Strain Sensitivity | 0.005 in/s/µstrain |
| Magnetic Field Sensitivity | < 51 µin/s/gauss (50 gauss, 50–60 Hz) |
| Weight | 0.142 kg (142 grams / 5.0 oz) |
| Diameter | 25.3 mm (0.995 in) |
| Height | 63.2 mm (2.49 in) |
| Case Material | 316L Stainless Steel |
| Connector | 2-pin MIL-C-5015 hermetically sealed |
| Mounting Torque | 32–46 kg·cm (24–40 in-lb) |
| Polarity Description | Motion toward connector makes Pin A positive vs Pin B |
FAQ
Frequently Asked Questions (FAQ)
Q1: What type of machines is this sensor suitable for?
A1: It is primarily used for rotating equipment such as pumps, fans, and compressors to monitor bearing housing or casing vibration.
Q2: Does it have restrictions on mounting orientation?
A2: No. It can be installed vertically, horizontally, or at any angle without affecting performance.
Q3: Does it require external electronics?
A3: No external electronics are needed. It has built-in solid-state electronics and outputs velocity signals directly.
Q4: What is the maximum cable length supported?
A4: Up to 305 meters (1000 feet) using the specified cable without signal degradation.
Q5: What are the key advantages of this sensor?
A5: It features no moving parts, high reliability, wide frequency response, and resistance to environmental interference.
Q6: How does the case material benefit the sensor?
A6: The 316L stainless steel construction allows use in corrosive or offshore environments.
Q7: Is the sensor certified for hazardous areas?
A7: Yes, it is certified with ATEX, IECEx, CSA for intrinsically safe and explosion-proof applications.
Q8: How can I ensure correct mounting location?
A8: Consult your equipment manufacturer or use Bently Nevada engineering services for transducer placement evaluation.
