Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 330980-50-05 (5.0 meters, panel mount) |
| Total System Length | 5.0 meters |
| Weight | 0.255 kg (Sensor only) |
| Linear Range | 0.25 mm to 1.75 mm (10 to 70 mils), nominal 1.5 mm |
| Recommended Gap | 1.0 mm (40 mils) |
| Scale Factor (Incremental) | 7.87 V/mm (200 mV/mil) ±12.5%/-20% |
| DSL (Deviation from Straight Line) | ±0.06 mm (±2.3 mils) |
| Frequency Response | 0 – 10 kHz (-3 dB) |
| Input Voltage Range | -17.5 Vdc to -26 Vdc |
| Power Consumption | Max 12 mA |
| Output Resistance | 50 Ohms |
| Operating Temperature (Probe) | -52°C to +177°C |
| Operating Temperature (Sensor) | -52°C to +100°C |
| Humidity | 100% condensing (non-submersible with protection) |
| Probe Tip Material | PPS (Polyphenylene Sulfide) |
| Probe Case Material | Stainless Steel AISI 304 |
| Sensor Housing Material | A380 Aluminum |
| Minimum Shaft Diameter | 30 mm standard, 20 mm with offset configuration |
| Minimum Counterbore Diameter | 9.5 mm |
| Minimum Bend Radius | 25.4 mm |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the total length of the 330980-50-05 sensor system?
A1: The total length is 5.0 meters, including probe and extension cable.
Q2: What is the typical weight of the Proximitor Sensor?
A2: The typical weight is approximately 0.255 kg (9 oz).
Q3: What type of output does the sensor provide?
A3: It provides a voltage output with a scale factor of 200 mV/mil (7.87 V/mm).
Q4: Can the 330980-50-05 be mounted on DIN rail?
A4: No, this model (50) is specified for panel mounting. DIN version is 51.
Q5: What is the recommended gap between the probe and the target?
A5: The recommended gap is 1.0 mm (40 mils).
Q6: What material is used for the probe tip and housing?
A6: The tip is made of PPS and the case is made of AISI 304 stainless steel.
Q7: What are the operating temperature ranges?
A7: The probe can operate from -52°C to +177°C, and the sensor from -52°C to +100°C.
Q8: Is the sensor resistant to RFI/EMI?
A8: Yes, the sensor features enhanced RFI/EMI immunity and meets CE standards.
