Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 330980-71-00 |
| Total System Length | 7.0 meters (probe + extension cable) |
| Weight | 0.255 kg (Proximitor Sensor only) |
| Input | Accepts 3300 NSv or 3300 RAM Proximity Probe and Extension Cable |
| Output Resistance | 50 Ω |
| Power Supply | -17.5 Vdc to -26 Vdc (without barriers), 12 mA max |
| Incremental Scale Factor (ISF) | 7.87 V/mm (200 mV/mil) |
| Linear Range | 1.5 mm (60 mils), from 0.25 mm to 1.75 mm |
| Recommended Gap | 1.0 mm (40 mils) |
| Target Size (Minimum Flat) | 8.9 mm diameter (recommended: ≥13 mm) |
| Minimum Shaft Diameter | 30 mm (X-Y config); 20 mm (offset config) |
| Frequency Response | 0 to 10 kHz, typical ±3 dB |
| Sensor Material | A380 aluminum |
| Probe Case Material | AISI 304 stainless steel |
| Connector Material | Gold-plated brass |
| Cable Type | 75 Ω coaxial FEP insulated |
| Operating Temp. (Sensor) | -52°C to +100°C |
| Storage Temp. (Sensor) | -52°C to +105°C |
| Operating Temp. (Probe) | -52°C to +177°C |
| Pressure Seal | Viton O-ring (differential pressure capable) |
| Relative Humidity | 100% condensing (non-submersible when sealed) |
| Minimum Bend Radius | 25.4 mm (1.0 in) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What is the total system length of the 330980-71-00 configuration?
A1: It is 7.0 meters, including the probe and extension cable.
Q2: What is the linear range of the 3300 XL NSv Proximitor Sensor?
A2: The linear range is 1.5 mm, from 0.25 mm to 1.75 mm.
Q3: Can this sensor be used with older 3300 RAM systems?
A3: Yes, the 3300 NSv probe and cable are compatible with 3300 RAM components.
Q4: What is the recommended gap setting for the probe?
A4: 1.0 mm (40 mils) is the recommended gap.
Q5: What type of materials are used for the probe case and sensor housing?
A5: The probe case is made from AISI 304 stainless steel, and the sensor is A380 aluminum.
Q6: What is the weight of the Proximitor Sensor alone?
A6: Approximately 0.255 kg (255 grams).
Q7: What is the frequency response of the system?
A7: 0 to 10 kHz with ±3 dB variation, depending on wiring length.
Q8: What environmental conditions can it withstand?
A8: Operating temperature ranges from -52°C to +100°C for the sensor and -52°C to +177°C for the probe.
