Technical Specifications
| Specification | Details |
|---|---|
| Power Consumption | 5.0 Watts (Modbus RS232/RS422 I/O Module) |
| 5.6 Watts (Modbus RS485 I/O Module) | |
| Data Types | Collects data from other modules such as current measured values with time stamps, module statuses, and current alarm statuses |
| Update Time | Data collection rate up to 1 second for all modules |
| Protocols Supported | Modbus RTU, Modbus/TCP, Bently Nevada proprietary protocol |
| Ethernet Communication | Ethernet, 10Mbps, conforms to IEEE802.3 |
| Connection | RJ-45 (10BASE-T Ethernet) |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 95%, non-condensing |
| Dimensions (Main Board) | 241 x 24.4 x 242 mm |
| Weight (Main Board) | 0.82 kg (1.8 lb.) |
| Dimensions (I/O Module) | 241 x 24.4 x 99.1 mm |
| Weight (I/O Module) | 0.44 kg (0.96 lb.) |
| Rack Space Requirements | 1 full-height front slot (Monitor Module) |
| 1 full-height rear slot (I/O Modules) |
FAQ
FAQ
Q1: What is the power consumption of the 3500/92 Communication Gateway Module?
A1: The power consumption is 5.0 Watts for Modbus RS232/RS422 I/O Module and 5.6 Watts for Modbus RS485 I/O Module.
Q2: How fast is the data update rate for the 3500/92 Communication Gateway Module?
A2: The data update rate will not exceed 1 second for all modules in the 3500 rack.
Q3: What protocols does the 3500/92 support?
A3: The 3500/92 supports Modbus RTU, Modbus/TCP, and the proprietary Bently Nevada protocol.
Q4: What are the operating temperature limits of the module?
A4: The operating temperature range is -30°C to +65°C (-22°F to +149°F).
Q5: What type of Ethernet communication is supported?
A5: The module supports 10BASE-T Ethernet communication, conforming to IEEE802.3 standards.
Q6: What are the dimensions of the 3500/92 Communication Gateway Module?
A6: The dimensions of the main board are 241 x 24.4 x 242 mm (9.50 in x 0.96 in x 9.52 in).
Q7: What is the weight of the main board and I/O modules?
A7: The main board weighs 0.82 kg (1.8 lb.), and each I/O module weighs 0.44 kg (0.96 lb.).
Q8: Where can I find more technical documentation and support?
A8: For additional technical documentation and support, visit the Bently Nevada Media Library or the official support page at bntechsupport.com.
