Technical Specifications
| Parameter | Specification |
|---|---|
| Cable Length | 99 ft (30.18 m) |
| Weight | 1.94 kg |
| Cable Type | Shielded 0.382 mm² (22 AWG) |
| Temperature Range | -29°C to +121°C (-20°F to +250°F) |
| Bend Radius | Minimum 51 mm (2.0 in) |
| Connector Type | 2-pin MIL-C-5015 receptacle, hermetically sealed |
| Cable Material | Stainless steel armor over shielded cable |
| Max Frequency Response | 15 to 2000 Hz (900 to 120,000 cpm) ± 3.0 dB |
| Max Cable Length | 305 meters (1000 ft) with no signal degradation |
FAQ
FAQs
Q1: What is the maximum temperature that the Bently Nevada 84661-99 Velomitor Interconnect Cable can withstand?
A1: The cable is designed to operate within a temperature range of -29°C to +121°C (-20°F to +250°F).
Q2: What is the cable’s length and weight?
A2: The cable length is 99 ft (30.18 meters), and its weight is 1.94 kg.
Q3: What is the minimum bend radius for this cable?
A3: The minimum bend radius for the cable is 51 mm (2.0 in).
Q4: What type of connector does the cable use?
A4: The cable uses a 2-pin MIL-C-5015 receptacle with a hermetically sealed stainless steel shell.
Q5: What is the electrical sensitivity of the cable?
A5: The electrical sensitivity of the cable is 5.7 mV/mm/s (145 mV/in/s), ±5%.
Q6: Can the cable be used in hazardous areas?
A6: Yes, the cable has multiple approvals for hazardous areas, including CSA/US/C certifications in North America and ATEX/IECEx approvals in Europe.
Q7: What is the frequency response range for the cable?
A7: The frequency response of the cable is from 15 Hz to 2000 Hz (900 to 120,000 cpm), with a ±3.0 dB tolerance.
Q8: What material is used for the cable’s armor?
A8: The cable is armored with stainless steel for added protection.
