Technical Specifications
| Parameter | Specification |
|---|---|
| Input | 3300 NSv non-contact proximity probe and extension cable |
| Power Supply | 12 to 35 VDC |
| Output Signal | 4–20 mA DC, proportional to peak-to-peak vibration |
| Output Accuracy | ±1.5% of full scale |
| Frequency Response | 5 Hz to 6,000 Hz, +0, -3 dB |
| Probe Gap Range | 0.5 mm to 1.75 mm (20 to 55 mils) |
| Maximum Loop Resistance | 1000 Ω at 35 VDC |
| Current Limit | 23 mA typical |
| Zero and Span Adjustments | External, non-interacting |
| Signal Defeat (NOT OK) Response | Output < 3.6 mA within 100 μs after fault; restores in 2–3 s |
| Output Impedance (Prox Out) | 10 kΩ, calibrated for 10 MΩ load |
| Scale Factor (Prox Out) | 7.87 mV/μm (200 mV/mil) ±6.5%, worst case ±10% |
| Temperature Stability | ±10% from 0°C to +70°C |
| Operating Temperature (Transmitter) | -35°C to +85°C (-31°F to +185°F) |
| Storage Temperature (Transmitter) | -52°C to +100°C (-62°F to +212°F) |
| Operating Temperature (Probe) | -52°C to +177°C (-62°F to +351°F) |
| Humidity | 100% condensing, non-submerged |
| Dimensions | 100.1 x 73.9 x 53.3 mm |
| Weight | 0.43 kg (0.9 lbm) |
FAQ
Frequently Asked Questions (FAQ)
Q1: What probe does the 990 transmitter support?
A1: It supports the Bently Nevada 3300 NSv proximity probe and matching extension cable.
Q2: What type of signal does it output?
A2: It outputs a standard 4–20 mA signal proportional to peak-to-peak vibration.
Q3: Can it be used for diagnostic analysis?
A3: It provides basic trend data but is not suitable for detailed vibration diagnostics.
Q4: How is the signal output protected during probe failure?
A4: The transmitter will drop the output below 3.6 mA within 100 μs upon a NOT OK condition.
Q5: What is the power supply range?
A5: The unit requires 12 to 35 VDC.
Q6: Is signal isolation available for diagnostics?
A6: Yes, using the optional 122115-01 test adapter is recommended for isolating the PROX OUT signal.
Q7: What is the frequency range covered?
A7: The device operates within 5 Hz to 6,000 Hz.
Q8: Is it certified for hazardous locations?
A8: Yes, it is approved for ATEX Zone 0, Zone 2, and CSA Class I Div 2 hazardous locations.
